Behringer PMH660M 8-Channel Powered Mixer with FX (400 Watts)
No longer available at zZounds



zZounds Gear Experts Say...
400-watt powered mixer. 8 channels. Formerly PMX660M.
Overview
Behringer PMH660M 8-Channel Powered Mixer with FX (400 Watts)
The Europower PMH660M is the most compact powered mixer in our groundbreaking new PMX series. Its super-compact 400 Watts, 6 mono channels plus stereo tape return configuration is a powerful solution that will exceed your expectations.
With our revolutionary CoolAudio amplifier technology you get enormous power, incredible sonic performance and super-light weight delivered in an ultra-compact mixer that is nearly half the depth and weight of conventional powered mixers.
Along with 6 high-quality balanced low-impedance mic preamps, there are balanced high-impedance line inputs for direct connection of line sources or high-output instruments. Each PMH660M channel features a monitor send, an FX send and a switchable -30 dB pad.
The PMH660M also has 'big mixer' features like a 24-bit/46 kHz effects processor with 99 great-sounding Virtualizer presets, two 7-band graphic EQs (one each for the main and monitor signals), FBQ Feedback Detection and dual 5-segment LED output level meters. Plus, it features a standby switch that mutes all mic channels, so you can play music during your breaks without having to change the channels volume controls and lose your mix. Adding to the list of features are the integrated Voice Canceller which removes vocals for karaoke applications, Behringer's Speaker Processing function for enhanced performance with Behringer Eurolive or other professional speaker systems and professional Speakon… read more (r) connectors. The integrated carrying handle makes it easy to transport. read less
The Europower PMH660M is the most compact powered mixer in our groundbreaking new PMX series. Its super-compact 400 Watts, 6 mono channels plus stereo tape return configuration is a powerful solution that will exceed your expectations.
With our revolutionary CoolAudio amplifier technology you get enormous power, incredible sonic performance and super-light weight delivered in an ultra-compact mixer that is nearly half the depth and weight of conventional powered mixers.
Along with 6 high-quality balanced low-impedance mic preamps, there are balanced high-impedance line inputs for direct connection of line sources or high-output instruments. Each PMH660M channel features a monitor send, an FX send and a switchable -30 dB pad.
The PMH660M also has 'big mixer' features like a 24-bit/46 kHz effects processor with 99 great-sounding Virtualizer presets, two 7-band graphic EQs (one each for the main and monitor signals), FBQ Feedback Detection and dual 5-segment LED output level meters. Plus, it features a standby switch that mutes all mic channels, so you can play music during your breaks without having to change the channels volume controls and lose your mix. Adding to the list of features are the integrated Voice Canceller which removes vocals for karaoke applications, Behringer's Speaker Processing function for enhanced performance with Behringer Eurolive or other professional speaker systems and professional Speakon… read more (r) connectors. The integrated carrying handle makes it easy to transport. read less
Specs
Max. Output Power:
2 x 200 W @ 4 ohms
1 x 400 W @ 8 ohms
Speaker Outputs: Neutrik Speakon comparable
Mono Mic/Line Channels: 6 (XLR + 1/4 in. TRS)
Stereo Line Channels: No
Channel Inserts: No
Channel EQ: 3-band
Graphic EQ/FBQ Feedback Detection: 2 x 7-band EQ + FBQ
Phantom Power (+48 V): Yes
Aux Sends: 1 pre/1 post fader
24-Bit Digital FX Processor: 1
XPQ Surround Effect: No
Voice Canceler: Yes
Standby Switch: Yes
Speaker Processing: Yes
Power Amp Modes: Monitor + Main, Main bridge mode (or double mono)
Power Amp Inserts: No
Main Mix Line Outputs: 1 x 1/4 in. TRS
Mono Line Output: No
Monitor Line Outputs: 1 x 1/4 in. TRS
2-Track I/O (RCA conn.): Yes
Phones/Ctrl.Room Output: No
Dimensions H x W x D (approx.):
12 2/5 in. x 18 1/10 in. x 8 3/5 in. (315 x 460 x 220 mm)
Weight (approx.): 9.2 kg (20.2 lbs.)
Special Features:
Input pad; aux input with level control
Hi-Z line inputs on channels 1-6
2 x 200 W @ 4 ohms
1 x 400 W @ 8 ohms
Speaker Outputs: Neutrik Speakon comparable
Mono Mic/Line Channels: 6 (XLR + 1/4 in. TRS)
Stereo Line Channels: No
Channel Inserts: No
Channel EQ: 3-band
Graphic EQ/FBQ Feedback Detection: 2 x 7-band EQ + FBQ
Phantom Power (+48 V): Yes
Aux Sends: 1 pre/1 post fader
24-Bit Digital FX Processor: 1
XPQ Surround Effect: No
Voice Canceler: Yes
Standby Switch: Yes
Speaker Processing: Yes
Power Amp Modes: Monitor + Main, Main bridge mode (or double mono)
Power Amp Inserts: No
Main Mix Line Outputs: 1 x 1/4 in. TRS
Mono Line Output: No
Monitor Line Outputs: 1 x 1/4 in. TRS
2-Track I/O (RCA conn.): Yes
Phones/Ctrl.Room Output: No
Dimensions H x W x D (approx.):
12 2/5 in. x 18 1/10 in. x 8 3/5 in. (315 x 460 x 220 mm)
Weight (approx.): 9.2 kg (20.2 lbs.)
Special Features:
Input pad; aux input with level control
Hi-Z line inputs on channels 1-6
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Web: https://www.behringer.com/service.html
Web: https://www.behringer.com/service.html
Reviews
Reviewers gave this product an overall rating of 1.5 out of 5 stars.
(49 ratings)
Submitted March 11, 2006 by a customer from yahoo.com
"This amp has performance anxiety."
Verified Customer
zZounds has verified that this reviewer made a purchase from us.
I am very disappointed that the poweramp section can not drive loads less than 8-ohms for extended periods of time. It's knack for shutting down in the middle of a gig is inexcusable.
Sound
Sounds fine, when it works.
Features
Just the right amopunt of features. Nice effects.
Ease of Use
Very easy to figure out how to use.
Quality
You can not rely on this amp as a main PA. The amp shuts down if the output load is less than 8-ohms and most 2-way PA cabinets (i.e. woofer and horn with crossover)are about 6-ohms. This amp has failed at 3 out of 4 gigs. I had such high hopes for it.
Value
A great value on an amp that doesn't perform up to specifications is not such a great deal.
Manufacturer Support
Have not returned the unit yet, but did get a response to my concern about output loading restrictions.
The Wow Factor
Nice layout and not feature-heavy.
Musical Background:
Active Musician, Producer, Recording Engineer, Soundman
Musical Style:
Classic Rock
3 of 3 people (100%) people found this review helpful. Did you?
