Electro-Voice ELX200-15 Passive, Unpowered Speaker, 1x15"
zZounds Gear Experts Say...
Engineered to Electro-Voice's tight specs, this 15" passive speaker is ideal for pro installations, with 300 watts continuous/1200 watts peak power handling.
Overview
Get the smooth clarity of the EV sound in the right size to suit your needs with the Electro-Voice ELX200-15 Passive loudspeaker. The sub is a flexible, feature‑rich choice for DJs, mobile entertainers, bands, and musicians. Unpowered. Requires separate power amplifier.
Get the smooth clarity of the EV sound in the right size to suit your needs with the Electro-Voice ELX200-15 Passive loudspeaker. The sub is a flexible, feature‑rich choice for DJs, mobile entertainers, bands, and musicians.
The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.
Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The subwoofers pack powerful low-frequency output into a surprisingly compact footprint, and feature tuned 15 mm thick wood enclosures with a premium top-coat finish. The proprietary features that have made the other members of the EV portable speaker family a go-to for best-in-class performance are also present.
EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate,… read more linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.
- 1.4 inch DH-1C (1 inch exit) titanium compression driver for extended transparent high-frequency response.
- High-output EVS-15M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
- EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
read less
Get the smooth clarity of the EV sound in the right size to suit your needs with the Electro-Voice ELX200-15 Passive loudspeaker. The sub is a flexible, feature‑rich choice for DJs, mobile entertainers, bands, and musicians.
The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.
Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The subwoofers pack powerful low-frequency output into a surprisingly compact footprint, and feature tuned 15 mm thick wood enclosures with a premium top-coat finish. The proprietary features that have made the other members of the EV portable speaker family a go-to for best-in-class performance are also present.
EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate,… read more linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.
Features
- 1200 W (peak), 130 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices.- 1.4 inch DH-1C (1 inch exit) titanium compression driver for extended transparent high-frequency response.
- High-output EVS-15M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction.
- EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading.
WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.
Specs
- Frequency response (-3 dB): 77 Hz - 16 kHz1
- Frequency range (-10 dB): 52 Hz - 19 kHz1
- Axial sensitivity: 95 dB1
- Maximum SPL: 130 dB
- Rec. high-pass frequency: 42 Hz
- Coverage (H x V): 90˚ x 60˚
- Power handling: 300 W Continuous, 1200 W Peak
- LF transducer: EVS-15M 381 mm (15 in)
- HF transducer: DH-1C 1-inch titanium compression driver
- Crossover frequency: 1.6 kHz
- Nominal impedance: 8 ohms
- Minimum impedance: 7.0 ohms
- Connectors: Dual NL4
- Enclosure: Polypropylene
- Grille: 18 AWG steel with powdercoat
- Suspension: (3) M10 suspension points
- Color: Black
- Dimensions (H x W x D): 710 mm x 423 mm x 384 mm (28.0 in x 16.6 in x 15.1 in)
- Net weight: 18.7 kg (41.2 lb)
- Shipping weight: 21.4 kg (47.2 lb)
- Frequency range (-10 dB): 52 Hz - 19 kHz1
- Axial sensitivity: 95 dB1
- Maximum SPL: 130 dB
- Rec. high-pass frequency: 42 Hz
- Coverage (H x V): 90˚ x 60˚
- Power handling: 300 W Continuous, 1200 W Peak
- LF transducer: EVS-15M 381 mm (15 in)
- HF transducer: DH-1C 1-inch titanium compression driver
- Crossover frequency: 1.6 kHz
- Nominal impedance: 8 ohms
- Minimum impedance: 7.0 ohms
- Connectors: Dual NL4
- Enclosure: Polypropylene
- Grille: 18 AWG steel with powdercoat
- Suspension: (3) M10 suspension points
- Color: Black
- Dimensions (H x W x D): 710 mm x 423 mm x 384 mm (28.0 in x 16.6 in x 15.1 in)
- Net weight: 18.7 kg (41.2 lb)
- Shipping weight: 21.4 kg (47.2 lb)
Dimensions and Weight in Packaging
Single Speaker, Black
- Shipping Weight: 48.25 lbs
- Shipping Dimensions: 30 x 20 x 18 in
- Manufacturer Part Number (MPN): F.01U.326.057
Open Box (Very Good), Single Speaker, Black
- Shipping Weight: 48.25 lbs
- Shipping Dimensions: 30 x 20 x 18 in
- Manufacturer Part Number (MPN): F.01U.326.057
Open Box (Like New), Single Speaker, Black
- Shipping Weight: 48.25 lbs
- Shipping Dimensions: 30 x 20 x 18 in
- Manufacturer Part Number (MPN): F.01U.326.057
Single Speaker, White
- Shipping Weight: 47.2 lbs
- Shipping Dimensions: 30 x 20 x 18 in
- Manufacturer Part Number (MPN): ELX200-15-W
Note: Unpowered speaker, requires separate power amplifier.
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Phone: 800-289-0096
Email: technical.support@us.bosch.com
Web: https://electrovoice.com/contact-us/
Phone: 800-289-0096
Email: technical.support@us.bosch.com
Web: https://electrovoice.com/contact-us/
