Behringer PMP2000 14-Channel Powered Mixer (800 Watts)

The PMP2000 powered mixer delivers more power, better sound at less weight!

The PMP2000 mixer delivers 800 Watts of massive power and incredible performance through new-generation amplifier technology, crystal-clear sound plus an ultra-compact and lightweight design. The 24-bit stereo FX processor, IMP mic preamps and more round off this impressive package of power features.

Get massive power and great sound in a lightweight package!

Features
Ultra-compact 2 x 350-Watt stereo powered mixer (800 Watt bridged mode)

Ultra-Low Noise ULN design, high headroom and ultra-transparent audio

14-channel mixer section features 6 mono and 3 stereo channels plus separate CD/Tape inputs

Studio-grade 24-bit stereo FX processor with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects

9 high-quality IMP "Invisible" Mic Preamps with switchable +48 V phantom power for condenser microphones

Effective, extremely musical 3-band EQ, switchable Pad and Clip LEDs on all mono channels

Dual 9-band graphic EQ allows precise frequency correction of monitor and main outputs

Selectable stereo (main L/R) or double mono (main/monitor) amplifier operation mode

Multi-functional stereo Preamp outputs and stereo Power amp inputs for added flexibility

High-quality components and exceptionally rugged construction ensure long life

Conceived and designed by BEHRINGER Germany

Technical Info

Microphone Inputs
- Type: XLR, electronically balanced, discrete input circuit
- Frequency Response: <10 Hz-100 kHz (-1 dB), <10Hz- >200 kHz (-3 dB)
- Gain: +33 dB, +8 dB with pad
- Max Input Level: +12 dBu @ +12 dB gain
- Impedance: approx. 2.2 k ohms balanced/ 1.1 k ohms unbalanced
- Signal-to-Noise Ratio: 110 dB/ 114 dB A-weighted (-11 dBu IN @ +33 dB gain)

Distortion (THD+N): 0.001% / 0.008% A-weighted

Mono Line Inputs:
- Type: 1/4 inch TRS connectors, balanced
- Impedance: approx 80k ohms balanced, 40k ohms unbalanced
- Max Input Level: 30 dBu

Stereo Line Inputs
- Type: 1/4 inch TRS connectors, unbalanced
- Impedance: approx. 40k ohms unbalanced
- Max Input Level: +28 dBu

Equalizer:
- Low: 60 Hz / +/- 15 dB
- Mid: 700 Hz-8kHz/ +/- 15 dB
- High: 6 kHz / +/- 15 dB

Preamp Outputs left/mono & right:
- Type: 1/4 inch TRS connector, unbalanced
- Impedance: approx 1.5k ohms
- Max Output Level: +21 dBu

Monitor Output:
- Type: 1/4 inch TRS connectors, unbalanced
- Impedance: 1.5k ohms
- Max Output Level: +21 dBu

Power Amp Inputs:
- Type: 1/4 inch TRS connectors, unbalanced
- Impedance: approx 47k ohms
- Max Input Level: +21 dBu

Loudspeaker Outputs
- Type: Professional speaker connectors (compatible to Neutrik Speakon)

Load Impedance:
- Left/monitor: 4/8/16 ohms
- Right/mono main: 4/8/16 ohms
- Bridge: 8-16 ohms

DSP:
- Converter: 24-bit Texas Instruments, 24-bit Sigma-Delta, 64/128-times oversampling
- Sampling Rate: 40 kHz

Amplifier (Power Amp Output):
- Power @ 4 ohms: 350 w
- Power @ 8 ohms: 165 w
- Power @ 8 ohms (Bridge): 800 w

Power Supply:
- Mains Voltage: 120 V~, 60 Hz
- Power Consumption: max 1 kW
- Fuse: T 10 A H 250V
- Mains Connector: Standard IEC receptacle

Physical/Weight:
- Dimensions: approx. 11 x 18 1/8 x 10 5/8 inches
- Weight: 30.9 lbs

10 channels, 10 mic inputs, 2 x 350 watts, stereo or mono operation, and dual 9-band graphic EQs.
