Peavey Unity 6 Compact USB Digital Mixer

Peavey Unity 6 Compact USB Digital Mixer, New, Main

Peavey Unity 6 Compact USB Digital Mixer, New, Action Position Back

zZounds Gear Experts Say...

It may be small, but the Peavey Unity 6 mixer packs in a lot of features, including USB-C and Bluetooth connectivity, built-in effects, and more.

Overview

The Unity 6 Digital Mixer offers added flexibility and control for live sound, recording, streaming, and podcasting applications. Featuring USB-C computer audio, Bluetooth input, phantom power, and studio-quality EQ and effects, Unity 6 delivers professional sound in a straightforward, user-friendly design.

Whether you're managing a small live setup, producing content, rehearsing, or running audio for events, Unity 6 provides reliable performance and clean audio without a steep learning curve.

Features:

- Expanded Channel Control - More inputs and routing flexibility for handling larger live, recording, or streaming setups.

- USB-C & Bluetooth Connectivity - Easily mix computer audio and wireless devices alongside microphones and instruments.

- Professional Sound Processing - Studio-quality EQ and built-in effects ensure clear, polished mixes with minimal setup.

- Phantom Power Support - Ready for condenser microphones in vocals, instruments, and spoken-word applications.

- User-Friendly Workflow - Intuitive layout and simple controls deliver pro results without a steep learning curve.

WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

Specs

- Input Connections:
- MIC/LINE (mono): Combo female XLR/ 1/4" jack (Balanced or unbalanced)
- Guitar (mono): 1/4" phone jack (Balanced or unbalanced)
- Line 3/4-5/6 (stereo): RCA,1/4" phone jacks, 3.5mm (Balanced or unbalanced)
- Mic Headset (mono): 3.5mm jack
- USB 1-2 (stereo): USB-B and USB-C
- Bluetooth (stereo): Yes

- Output Connections:
- Main Out (stereo): 1/4" phone jacks (Balanced or unbalanced)
- Monitor Out (mono): 1/4" phone jack (Balanced or unbalanced)
- Headphone Out (stereo): 1/4" phone jack (Unbalanced)
- Headset Out (stereo): 3.5mm jack (Unbalanced)
- USB 1-2 (stereo): USB-B and USB-C

- Channel Function:
- Mic 1: Low-cut, Noise gate, Compressor, 3-band EQ, EFX's, Volume, Mute
- Mic 2: Low-cut, Noise gate, Compressor, 3-band EQ, EFX's, Volume, Mute
- Guitar: Noise gate, Compressor, 3-band EQ, EFX's, Volume, Mute
- Line 3/4: Noise gate, 3-band EQ, EFX's, Volume, Mute
- USB 1-2: 3-band EQ, Volume, Mute

- Nominal Frequency Response: +0, -1 dB from 10 Hz to 23 kHz
- Hum and Noise: < -90 dBu
- Phantom Power Voltage: +48 V DC
Power requirements: 5V DC, 2 Amp
Dimensions (W x D x H): 6.625 x 8.25 x 2.75 in / 168 x 210 x 70 mm
- Net Weight: 2.31 lbs. / 1.05 kg

Dimensions and Weight in Packaging

Base Item

Shipping Weight: 3.37 lbs
Shipping Dimensions: 11 x 10 x 4 in
Manufacturer Part Number (MPN): 03622370
