- Pole Socket Size: 1-3/8" (35 mm)
- Dimensions: (L x W x H) 23.63 x 20.63 x 31.19"
- Weight: 82.6 lbs
Frequency Response, 1 meter on-axis, swept-sine in anechoic environment: 64 Hz to 17 kHz (±3 dB)
Usable Low Frequency limit (-10 dB point): 49 Hz
Full Range: 500 W continuous, 1,000 W program, 2,000 W peak
Low Frequency Section: 500 W continuous, 1,000 W program, 2,000 W peak
High Frequency Section: 50 W continuous, 100 W program, 200 W peak
Sensitivity/Sound Pressure Level, 1 Watt, 1 meter in anechoic environment:
Full Range: 97 dB SPL, (2.83 V input)
Low Frequency Section: 98 dB SPL, (2.83 V input)
High Frequency Section: 105 dB SPL, (2.83 V input)
Maximum Sound Pressure Level (1 meter):
Full Range: 124 dB SPL continuous, 130 dB SPL peak
Low Frequency Section: 125 dB SPL continuous, 131 dB SPL peak
High Frequency Section: 125 dB SPL continuous, 131 dB SPL peak
Radiation Angle measured at -6 dB point of polar response:
100 deg. Horizontal by 50 deg. Vertical
The vertical main polar lobe is angled down 10 degrees with respect to straight ahead, the vertical coverage angles being +15. –35 deg.
Low Frequency Section: 1 x 15” woofer, vented; Black Widow® 1508-8 SPS
High Frequency Section: 1 x 1.0” exit, 50 mm voice coilRX22CT compression driver on asymmetrical Quadratic Throat CD Horn
Box Tuning Frequency:
Low Frequency Section: 50 Hz
Electroacoustic Crossover Frequency (internal passive):
Low Frequency - High Frequency: 1,800 Hz
Recommended Active Crossover Frequency Region and Slope:Low Frequency - High Frequency: 2.0 kHz at 24 dB/octave LR
Low Frequency: 0.0 ms
High Frequency: 0.31 ms
Full Range: Nominal: 8.0 Ω, Minimum 6.0 Ω
Low Frequency: Nominal: 8.0 Ω, Minimum: 6.0 Ω
High Frequency: Nominal:8.0 Ω, Minimum: 7.9 Ω
Full range: two 1/4” phone jacks, one four-pin, twist lock connector & one Neutrik NL4 Speakon switching jack (bi-amp only)
Enclosure Materials & Finish: Plywood coated with a textured black polyurethane finish. Full length black powder coated metal grille.
Mounting provisions: M8 Threaded Mounting Suspension Points (3 top, 3 bottom and 2 each side & 1 each top rear and bottom rear).
Built-in stand-mount adapter and four large rubber feet on bottom for floor use.
- Dimensions and Weight in Packaging
- Base Item
Shipping Weight: 60.75 lbs
Shipping Dimensions: 30 x 21 x 20 in
Manufacturer Part Number (MPN): 03614800
