Shure ULXD4D-H50 Dual Digital Wireless Receiver
zZounds Gear Experts Say...
Acquire pristine wireless signal for two different sources with this top-of-the-line digital wireless receiver, delivering premium 24-bit/48 kHz audio.

The Shure ULXD4D Dual Channel Digital Wireless Receiver offers two channels of uncompromising audio quality, RF signal stability, and advanced setup features in a space-efficient single rack unit. Digital wireless processing delivers premium 24-bit/48 kHz audio and RF spectrum efficiencies that dramatically increase the number of available compatible channels. With an expansive set of enhanced features including AES 256-bit encryption for security and Dante digital networking for audio over Ethernet, the ULXD4D brings a powerful level of performance to professional sound reinforcement.

Features:

- Two receivers in a rugged 1RU metal chassis with internal power supply
- Individual gain controls, LED meters, and XLR outputs for each channel
- Up to 64 MHz tuning range (region dependent)
- Digital predictive switching diversity
- High Density mode optimizes ULX-D systems to simultaneously operate significantly more channels in applications up to 30 meters
- RF cascade ports allow distribution of RF signal to another unit
- Optimized scanning automatically finds, prioritizes, and deploys the cleanest frequencies to transmitters over IR sync
- Bodypack Frequency Diversity ensures uninterrupted audio for mission-critical applications
- AES 256-bit encryption-enabled for secure transmission
- Audio summing routes both audio channels to each XLR receiver output
- Dante Domain Manager compatible
- Up to 60 dB independently adjustable gain for each channel
- Ethernet networking for… read more streamlined frequency coordination and deployment across multiple receivers
- Wireless Workbench6 (WWB6) software integration for advanced coordination, monitoring, and control
- Interference detection and alerts provided on both the receiver and WWB6
- AMX/Crestron control
- AXT600 AxientSpectrum Manager compatible
- Intuitive front panel LCD menu and controls with lockout feature
- Audio and RF LED meters with peak indicator
- XLR connectors with switchable mic/line output level
- Remoteable 1/2 wave antennas read less

-Dimensions (HxWxD): 44 x 482 x 274 mm (1.73 x 18.97 x 10.79 in.)
-Weight: 3.36 kg (7.4 lbs), without antennas
-Housing: Steel; Extruded Aluminum
-Power Requirements: 100 to 240 V AC, 50-60 Hz, 0.26 A max.
-Spurious Rejection: >80 dB, typical
-Connector Type: BNC
-Impedance: 50 ohms
-Bias Voltage: 12-13 V DC, 150 mA maximum, per antenna
-Gain Adjustment Range: -18 to +42 dB in 1 dB steps (plus Mute setting)
-Configuration: XLR: Balanced (1=ground, 2=audio +, 3=audio -)
-Impedance: 100 ohms
-Full Scale Output: LINE setting= +18 dBV, MIC setting= -12 dBV
-Mic/Line Switch: 30 dB pad
-Phantom Power Protection: Yes
-Network Interface: Dual Port Ethernet 10/100 Mbps, 1 Gbps
-Network Addressing Capability: DHCP or Manual IP address
-Maximum Ethernet Cable Length: 100 m (328 ft)
-Connector Type BNC: For connection of 1 additional receiver
-Configuration: Unbalanced, passive
-Impedance: 50 ohms
-Insertion Loss: 0 dB
