Rupert Neve Designs RNDI-S Stereo Active Transformer DI Box

Rupert Neve Designs RNDI-S Stereo Active Transformer DI Box, New, Angled Front

Rupert Neve Designs RNDI-S Stereo Active Transformer DI Box, New, In Use

Rupert Neve Designs RNDI-S Stereo Active Transformer DI Box, New, Angled Back

zZounds Gear Experts Say...

Not your average DI box, the RNDI-S direct box uses custom RND transformers with Class-A biased, discrete FET amplifiers for a powerful and vibrant sound!

Overview

The Rupert Neve Designs RNDI-S has a signature sound which is the product of custom Rupert Neve Designs transformers and class-A biased, discrete FET amplifiers. The carefully orchestrated union of these two elements is key to the unique response of the RNDI-S, delivering a powerful and vibrant direct sound capable of reproducing the full harmonic depth of basses, guitars, keyboards, acoustic instruments, professional line-level sources and consumer devices with a 3.5mm jack.

Hear Switched On's vintage synths through the RNDI-S direct box:

Features:

- Custom Rupert Neve Designs transformers for rich, powerful tone
- Exceptional performance with any instrument
- Unrivaled clarity from discrete FET amplifiers
- Drives long lines with minimal loss
- Rugged steel frame built for life on the road
- Powered by dual 48V phantom power
- Excellent phase coherence at all frequencies

Specs

- Dimensions (W x D x H): 7"x 5" x 1.75"
- Noise (Measured Output, Un-weighted, Source Impedance 150 ohms, 22Hz - 22kHz ): Better than -110dBV

- Input Impedance:
- Instrument Input: 2.2 Megohm
- 3.5mm Input: 95 Kilohm

- Output Impedance: Less than 40 Ohms

- Frequency Response:
- 30Hz-63KHz: +/- 0.25 dB
- 12Hz-120Khz. +/- 1dB

- Maximum Input Level: +20.5 dBu Typical
- Maximum Output Level: +11.5 dBu Typical
- Total Harmonic Distorion + Noise:
- @ 1 kHz, -20 dBu Input Level, no load : 0.009% Typical (2nd and 3rd Harmonic)
- @ 1 kHz, +20 dBu Input Level, no load : 0.35% Typical (2nd and 3rd Harmonic)
- @ 20 Hz, -20 dBu Input Level, no load : 0.9% Typical (2nd and 3rd Harmonic)

- Crosstalk: @ 10 kHz
- Instrument Input: -115 dB
- 3.5 mm Input: -108 dB

- Power Requirements:
- Phantom Powered: 4.5mA Per Channel @ 48VDC
- 19" Rack Shelf Mounting Option: 4 hole pattern (bottom of unit) for 6-32 machine screws

Dimensions and Weight in Packaging
Base Item: Shipping Weight: 3 lbs; Shipping Dimensions: 10 x 8 x 3 in; Manufacturer Part Number (MPN): RNDI-S

Documents and Manuals

For support or warranty questions, please contact the manufacturer:
Email: service@rupertneve.com
Web: https://rupertneve.com/support

Reviews

(1 ratings)

Submitted February 6, 2025 by a customer from yahoo.com

"Unlocks studios hidden potential."

Overall:

(see rating details)

Verified Purchaser zZounds has verified that this reviewer purchased this specific product from us.

I did many tests comparing my signal using No DI, Radial DI, and Neve DI. The results were staggering. Even Radial pales in comparison. Clarity, & detail you have to hear to truly believe. Makes my Prophet 10 soar. The neve DI is the one teammate that makes every teammate around them play better. Most important piece of gear I own.
