Phenyx Pro PTM-11-1B UHF Mono Wireless In-Ear Monitor System
zZounds Gear Experts Say...
Operation in the UHF band with 50 selectable frequencies makes the Phenyx Pro PTM-11-1B an impressive entry-level wireless IEM option.
Overview
Available here in the PTM-11-1B configuration with 1 bodypack receiver, Phenyx Pro's PTM-11 wireless IEM system tackles the challenges of monitoring live performances, allowing you to freely move on stage, engage with fans, and personalize your monitoring experience. The flexible and diversified mono monitoring experience lets you focus more on your content. With convenient loop outputs, the exceptional entry-level monitoring solution allows you to better navigate your music adventures.
Note: The PTM-11 transmitter is capable of sending a single monitor mix. Each bodypack receiver connected to this transmitter receives the same, unified monitor mix.
- The PAD button lowers the input gain to prevent loud input sources from overloading and clipping the preamplifier.
- The LOOP OUT design for flexible routing operation.
- One stand-alone mix offers a flexible and diverse monitoring experience.
- Selectable UHF frequency design to avoid interference easily.
- Quick IR sync and one-touch frequency selection for fuss-free operation.
- One transmitter base unit can add as many bodypack receivers as you need.
- Rugged-built receivers and bodypacks with a sleek design.
- Rack-mountable with brackets included in the package.
- Up to 164ft/50m free operation range.
- Operates in the 900MHz/500MHz range:
-- 902.35 - 914.6 MHz (50 frequencies)
-- 530.05 - 542.3 MHz (50 frequencies).
- PTM-11… read more supports multi-set operation with up to 5 systems in the 900 MHz band and up to 4 systems in the 500 MHz band
read less
Note: The PTM-11 transmitter is capable of sending a single monitor mix. Each bodypack receiver connected to this transmitter receives the same, unified monitor mix.
Features:
- Crystal-clear mono audio without latency lasts throughout your whole performance.- The PAD button lowers the input gain to prevent loud input sources from overloading and clipping the preamplifier.
- The LOOP OUT design for flexible routing operation.
- One stand-alone mix offers a flexible and diverse monitoring experience.
- Selectable UHF frequency design to avoid interference easily.
- Quick IR sync and one-touch frequency selection for fuss-free operation.
- One transmitter base unit can add as many bodypack receivers as you need.
- Rugged-built receivers and bodypacks with a sleek design.
- Rack-mountable with brackets included in the package.
- Up to 164ft/50m free operation range.
- Operates in the 900MHz/500MHz range:
-- 902.35 - 914.6 MHz (50 frequencies)
-- 530.05 - 542.3 MHz (50 frequencies).
- PTM-11… read more supports multi-set operation with up to 5 systems in the 900 MHz band and up to 4 systems in the 500 MHz band
Specs
- Frequency Range: 902.35 - 914.6 MHz or 530.05 - 542.3 MHz
- Transmitter output level: 10dBm
- Dynamic range: >90dBm
- Frequency response: 50Hz - 16KHz
- Working distance: 50m/164ft
- Transmitter Max audio input level: +6dBV
- Transmitter Gain adjustment range: 40dB
- Transmitter Input impedance: 6.8kO
- Transmitter Power requirement: INPUT: AC 110V - 240V, 50/60 Hz; OUTPUT: DC 13.5V, 500mA
- Bodypack Audio input level: 80mV
- Bodypack Sensitivity: -90dBm
- Bodypack Battery life: >6 hours
- Transmitter output level: 10dBm
- Dynamic range: >90dBm
- Frequency response: 50Hz - 16KHz
- Working distance: 50m/164ft
- Transmitter Max audio input level: +6dBV
- Transmitter Gain adjustment range: 40dB
- Transmitter Input impedance: 6.8kO
- Transmitter Power requirement: INPUT: AC 110V - 240V, 50/60 Hz; OUTPUT: DC 13.5V, 500mA
- Bodypack Audio input level: 80mV
- Bodypack Sensitivity: -90dBm
- Bodypack Battery life: >6 hours
Dimensions and Weight in Packaging
530 - 542 MHz, PTM-11-1B-500
- Shipping Weight: 5.45 lbs
- Shipping Dimensions: 15 x 14 x 4 in
- Manufacturer Part Number (MPN): PTM-11-1B 500
902 - 915 MHz, PTM-11-1B-900
- Shipping Weight: 5.56 lbs
- Shipping Dimensions: 15 x 14 x 4 in
- Manufacturer Part Number (MPN): PTM-11-1B 900
