Eminence LA6-CBMR Line Array Speaker (150 Watts)

Eminence LA6-CBMR Line Array Speaker (150 Watts), 6.5 inch, 8 Ohms, Side--LA6 CBMR

Eminence's LA6-CBMR speaker has a 6" basket diameter to fit line array PA cabinets. It's an ideal midrange driver, with a frequency range of 500 Hz to 3 kHz.

Overview

The Eminence LA6-CBMR is recommended for pro audio midrange applications from 500Hz-3kHz. Features a closed truncated basket for close spacing in line arrays.

Take an in-depth tour of the Eminence speaker factory:

Features:

- Copper voice coil
- Polyimide former coil
- Ferrite magnet
- Vented and extended core
- Pressed steel basket with truncated sides
- Paper cone/cloth cone edge
- Solid composition paper dusct cap

WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

Specs

- Nominal Basket Diameter: 6", 165 mm
- Nominal Impedance: 8 Ohm
- Power Rating:
- Watts 150 W
- Music Program 300 W
- Resonance : 460 Hz
- Usable Frequency Range: 500 Hz - 5.4 kHz
- Sensitivity: 97.8 dB
- Magnet Weight: 38 oz.
- Gap Height: 0.31", 7.9 mm
- Voice Coil Diameter: 1.5", 38 mm
- Coil Construction: Copper voice coil
- Coil Former: Polyimide former
- Magnet Composition: Ferrite magnet
- Core Details: Vented and extended core
- Basket Materials: Pressed steel basket with truncated sides
- Cone Composition: Paper cone
- Cone Edge Composition: Cloth cone edge
- Dust Cap Composition: Solid composition paper dust cap

Dimensions and Weight in Packaging
6.5 inch, 8 Ohms: Shipping Weight: 3.25 lbs; Shipping Dimensions: 8 x 8 x 5 in; Manufacturer Part Number (MPN): LA6-CBMR
