- OSCILLATORS:- 2 digitally controlled analog oscillators (DCOs) per voice (plus sub octave on oscillator 1) with selectable sawtooth, triangle, saw/triangle mix, and pulse waves (with pulse-width modulation)
- Glide (portamento): separate rates per oscillator
- White noise generator
- Analog VCAs
- Hard sync
- FILTERS:- 1 analog Curtis low-pass filter per voice, selectable 2- and 4-pole operation (self-resonating in 4-pole mode)
- ENVELOPES
- 3 envelope generators: filter, VCA, and assignable (four-stage ADSR + delay); Envelope 3 can loop.
- SEQUENCER:- Polyphonic step sequencer with up to 64 steps (6 notes per step), and ties and rests. Separate 16 x 4 gated step sequencer. Each layer can have a separate sequence.
- LFOS
- 4 LFO's with key sync per LFO
- MODULATION:- 8-slot modulation matrix
- ARPEGGIATOR:- Programmable arpeggiator with up, down, up+down, random, assign modes
- Selectable note value: 16th note, 8th note triplet, 8th note, dotted 8th note, quarter note
- One, two, or three octave range
- Re-latching arpeggiation
- Note repeat
- CONTROLS:- 5-octave keyboard with semi-weighted action, velocity, and aftertouch
- 52 knobs and 20 buttons enable deep and comprehensive editing with little to no menu diving.
- Spring-loaded pitch wheel and assignable mod wheel
- MEMORY:- 512 Factory Programs (4 banks of 128) and 512 fully editable User Programs with 2 layers (2 separate sounds) in each Program
- IN/OUT:- MIDI In, Out, Thru
- Main stereo audio output: 1/4\0x2033 unbalanced
- Output B stereo audio output: 1/4\0x2033 unbalanced
- Sustain pedal input: accepts normally on or normally off momentary footswitch.
- Pedal/CV input: responds to expression pedals or control voltages ranging from 0 to 5 VDC (protected against higher or negative voltages).
- Headphone output: 1/4\0x2033 stereo phone jack.
- POWER:- IEC AC power inlet for internal power supply
- Operates worldwide on voltages between 100 and 240 volts at 50 to 60 Hz
- Power consumption: 22 watts maximum (17 watts for 8-voice configuration; 22 watts for 16-voice configuration)
- PHYSICAL SPECS:- Oiled African mahogany wood end panels
- Dimensions: 12.70\0x2033 (32.26 cm) W x 35.12\0x2033 (89.20 cm) L x 3.80\0x2033 (9.65 cm) H (2.30\0x2033 at front edge; the feet account for 0.25\0x2033 of the total height)
- Weight: 20.5 lbs. (9.3 kg)
- Dimensions and Weight in Packaging
- Base Item
-
Shipping Weight: 26.5 lbs
-
Shipping Dimensions: 41 x 19 x 9 in
-
Manufacturer Part Number (MPN): DSI-2808
