- Nominal Input Level: MIC IN: -40 dBu (MicSens = 40) AUX IN: TBD
- Input Impedance: MIC IN: 4 k ohms AUX IN: 22 k ohms
- Nominal Output Level: XLR OUT: -40 dBu PHONES/LINE: TBD
- Output Impedance: XLR OUT: 600 ohms PHONES/LINE: 66 ohms
- Memory: Sound: 50
- Effect Types: DYNAMICS, PITCH CORRECT, TONE/SFX, DOUBLE/HARMONY, DELAY, REVERB
- Phrase Loop
- 38 sec. (Mono only)
- Display: 16 characters, 2 lines (backlit LCD)
- Connectors: MIC IN jack/XLR type (balanced, phantom power: DC 48 V, 10 mA Max), 1/4 inch TRS phone type (balanced) AUX IN jack (Stereo miniature phone type) XLR OUT jack (XLR type) PHONES/LINE jack (Stereo miniature phone type) CTL 1, 2 Jack (1/4" TRS phone type) DC IN Jack (DC 9 V)
- Power Supply: Rechargeable Ni-MH Battery (AA, HR6) or Alkaline (AA, LR6) x 4,
AC Adaptor (PSA series: sold separately)- Current Draw: TBD
- Expected battery life under continuous use
- Rechargeable Ni-MH Battery (AA, HR6): TBD Alkaline (AA, LR6) : TBD * These figures will vary depending on the specifications of the batteries and the actual conditions of use. * Using phantom power will increase the power consumption, drastically shortening the battery life. Please use an AC adaptor when using phantom power.
- Accessories: Owner's Manual Leaflet (USING THE UNIT SAFELY, IMPORTANT NOTES, and Information) Mic Stand Holder (Screw x 2, Washer x 2, Spring Washer x 2) Audio Cable (Stereo Miniature Phone Type, Cable Tie Attached) Alkaline Battery (AA, LR6) x 4
- Options (sold separately): AC Adaptor (PSA series) Footswitch (FS-5U, FS-6)
- Dimensions and Weight in Packaging
- White
-
Shipping Weight: 2.5 lbs
-
Shipping Dimensions: 11 x 7 x 5 in
-
Manufacturer Part Number (MPN): VE-5-WH
