Audio-Technica PRO 24-CM Stereo Condenser Microphone

zZounds Gear Experts Say...

This condenser mic is equipped with pair of cardioid elements that reproduce the depth and realism of live sound with stunning clarity.

Overview

The PRO24CM camcorder microphone is a lightweight, compact stereo condenser ideal for digital recording with high-fidelity stereo sound. Equipped with an accessory shoe and permanently attached coiled cable, the microphone features a pair of cardioid elements in an X-Y configuration to provide the spatial impact and realism of a live sound field. The microphone is designed for either battery operation or battery-free operation when used with camcorders that provide plug-in power at the mic input. Like all Audio-Technica mics, the PRO24CM is rugged; it's built to endure the rigors of field production.

Features:

- Stereo microphone designed to attach to a camcorder
- For camcorders with an accessory shoe and stereo microphone input
- Lightweight, portable design with rugged all-metal construction
- Pair of cardioid condenser elements provides spatial impact and high-fidelity stereo sound image
- Battery-free operation when used with recording devices that provide plug-in power at the mic input
- On/off switch for convenient operation
- Includes camera-mount, windscreen, battery and protective pouch
- Permanently attached 6-12 in. coiled cable with right-angle molded 3.5 mm stereo mini plug at output end

Specs

Elements: Fixed-charge back plate permanently polarized condenser

Polar pattern: X/Y stereo

Frequency response: 100-17,000 hz

Open circuit sensitivity: -50 db (3.1 Mv) RE 1v at 1 PA

Impedance: 600 ohms

Maximum input sound level: 119 dB SPL, 1 khz at 1% T.H.D.

Dynamic range (typical): 82 dB, 1 khz at Max SPL

Signal-to-noise ratio: 57 dB, 1 kHz at 1 PA

Power requirements: 2-10v DC plug-in power

Battery type: 1.5V lR44

Battery current / life 0.6 Ma / 200 hours typical

Switch: On/off

Weight: 3.9 Oz (111 g)

Dimensions: 4.59 in. (116.5 Mm) long, 0.83 in. (21.0 Mm) maximum body diameter

Output connector: 3.5 mm stereo mini plug on cable

Cable: permanently attached 152.4 mm - 304.8 mm (6 in.-12 in.) coiled cable with right-angle molded 3.5 mm stereo mini-plug at output end

Accessories furnished: Video-camera shoe mount; LR44 battery; windscreen; soft protective pouch

Audio-Technica case style: S10

Dimensions and Weight in Packaging
with Camera Mount: Shipping Weight: 1.75 lbs; Shipping Dimensions: 12 x 7 x 4 in; Manufacturer Part Number (MPN): PRO24CM
