QSC RMX5050 Power Amplifier

QSC's RMX 5050 power amplifier represents the state-of-the-art in professional quality performance at an affordable price. Perfectly suited for a wide range of sound reinforcement applications including professional touring, performing musicians, and mobile entertainers, the RMX 5050 is optimized to deliver high levels of sustained power, extraordinary audio performance and road-proven reliability.

Like its smaller sibling (the RMX 4050HD), the RMX 5050 features a three-tier, Class H design. The RMX 5050 is extremely efficient at real world power levels. Less AC current is wasted and more goes into producing useful audio power. The RMX 5050 uses the best available component upgrades to increase peak power by 25% over the RMX 4050HD.

Like all RMX amps, the RMX 5050 features balanced 1/4 in. TRS, XLR and barrier strip inputs, binding posts and Neutrik Speakon outputs, front-mounted gain controls, plus signal and clip LED indicators to monitor performance.

Features:
The new flagship of the RMX line, the RMX 5050 provides extremely high power and represents tremendous value

The RMX 5050 provides advanced thermal performance, delivering higher continuous power in 2-ohms stereo or 4-ohms bridged applications

Dual mono, high current power supply for increased reliability and performance

3RU chassis only 16 in. deep

Professional quality performance?incorporates road-proven QSC designs

High-current toroidal transformers for greater two-ohm power and low noise

Independent user-defeatable clip limiters reduce distortion

Selectable low-frequency filters (30 Hz or 50 Hz) protect speakers and increase headroom

Balanced 1/4 in. (6.3 mm) TRS, XLR, and barrier strip inputs for maximum flexibility

Binding post and Neutrik Speakon outputs

Front mounted gain controls for easy access

Signal and Clip LED indicators to monitor performance

Requires 20-amp outlet

3-year warranty

Technical Info

Stereo Mode, Both Channels Driven
8 ohms (FTC 20 Hz-20 kHz 0.1% THD): 1050 Watts
4 ohms (FTC 20 Hz-20 kHz 0.1% THD): 1600 Watts
2 ohms (FTC 20 Hz-20 kHz 0.1% THD): 2000 Watts
8 ohms (EIA 1 kHz 0.1% THD): 1100 Watts
4 ohms (EIA 1 kHz 0.1% THD): 1800 Watts
2 ohms (EIA 1 kHz 1% THD): 2500 Watts

Bridge-Mono Mode
8 ohms (FTC 20 Hz-20 kHz 0.1% THD): 3200 Watts
8 ohms (EIA 1 kHz 0.1% THD): 3600 Watts
4 ohms (EIA 1 kHz 1% THD): 5000 Watts

Distortion (SMPTE-IM) Less than 0.02%

Distortion (Typical)
20 Hz-20 kHz: 10 dB below rated power: Less than 0.02%
1 kHz and below: full rated power: Less than 0.02%

Frequency Response: 20 Hz to 20 kHz, 8 ohms, LF filter bypassed, +0/-1 dB
5 Hz to 50 kHz, 8 ohms, LF filter bypassed, +0/-3 dB

Damping Factor: Greater than 250 @ 8 ohm

Noise (unweighted): 100 dB below rated output (20 Hz to 20 kHz, 8 ohm load)

Input Sensitivity: 1.42 Vrms for 1050 watts into 8 ohms

Controls Front: AC power switch, Ch. 1 and Ch. 2 gain control

Controls Rear: 10-pole DIP switch featuring LF filter on/off, LF filter 30/50 Hz, Clip Limiter on/off controls for each channel and switches for selecting Stereo, Parallel, or Bridge mode. Push-button circuit breaker for each channel.

Voltage Gain: 64x (36 dB) for 8 ohm load

Input Impedance: 20 k ohm balanced, 10 k ohm unbalanced

Indicators
Power-On: Green LED, Protect: Red LED
Signal -30dB: Yellow LED, Clip: Red LED

Connectors Input: XLR female, TRS (1/4-inch), and barrier-strip screw terminals, each channel

Connectors Output: Binding posts and Speakon outputs (Ch. 1 Speakon wired for biamp)

Cooling: Continuously variable-speed fan, rear-to-front air flow

Amplifier Protection: Short circuit, open circuit, thermal, ultrasonic, and RF protection. Stable into reactive or mismatched loads

Load Protection: On/off muting, DC fault output crowbar

Power Requirements: 100, 120 or 240 Volts AC (+/-10%) 50-60 Hz (factory configured)120V models require 20 Amp, 120V service and are supplied with a NEMA 5-20 plug on the cordset.

Dimensions (W x H x D): 19.0 x 5.25 x 15.9 in. (48.3 x 13.3 x 40.39 cm)

Weight: 75 lb (34.02 kg) net, 87 lb (39.46 kg) shipping

Note: Register your new product online with QSC and receive a Free 6-Year Extended Warranty upgrade (a $99 value).

Rebates

This flagship of the RMX series produces 1050 watts/channel at 8 ohms, 5000 watts at 4 ohms bridged.
