dbx 215 Dual 15-Band Graphic Equalizer

The dbx 2-Series Graphic Equalizers have been designed to meet the needs of the most demanding sound reinforcement environments, while offering the simplicity of straight forward controls. The 215 not only provides standard features like dual channels, 15 2/3 octave bands, ISO frequency meters, +/- 12dB input gain range, and switchable 50Hz/12dB octave low-cut filters, but also includes other thoughtful features. These features include: 20 mm faders; selectable +/-6dB or +/-12dB boost/cut range for precise gain adjustments; XLR, and 1/4 in. TRS connectors for installation ease; balanced inputs and outputs for quiet operation; and chassis/signal ground lift capabilities for quick hum isolation. The visionary design of the dbx 2-Series has been pursued to make your job easier.

The 2-Series represents a major step forward in the performance of entry-level graphic equalizers. From its amazing 10Hz to 50kHz frequency response, to its 108dB dynamic range, internal toroidal transformer, the 2-Series offers out-of-this-world specifications with a down to earth price point. Sure to find a home in the studio, on tour and with installed sound venues, the 2-Series is destined to take its rightful place in the lineage of great dbx signal processors that are the professional's choice in signal processing. With such affordable quality, there's no longer any excuse for compromising your sound.

Features:

Two 15-band, 2/3-octave Constant Q frequency bands

Switchable boost/cut ranges of ±6 or ±12 dB

Front panel bypass switch

4-segment LED ladders for monitoring output levels

XLR and TRS Inpts and Outputs

Internal Toroidal Transformer

Technical Info

Frequency Response: <10Hz to >50kHx

Dynamic Range: Greater than 108dB

Input Gain Range: ±12 dB

12dB per octave, 3dB down @ 50Hz low-cut filter

Stereo 15-band 2/3-octave EQ! Switchable 6 or 12dB boost/cut range. Low cut filter at 50Hz. Front panel bypass switches and output level meters. XLR and TRS I/O.
