zZounds Gear Experts Say...
With a big, full-range sound and amazing mid/treble clarity, the Yamaha DHR15 PA speaker ensures that your audience hears every nuance of the performance.

The Yamaha DHR15 powered loudspeaker features a rugged wooden cabinet, 1000 Watts of Class D power and DSP to produce up to 131dB SPL with remarkable clarity. A flexible 2 channel mixer allows for multiple sources and connection types. Rigging points are also provided for suspended applications.

Features:

- 1.4" precision HF compression drivers
- Strong plywood cabinets with a tough polyurea coating
- Ultra-Precise 48bit (76bit Accumulator) DSP processing
- Employs FIR-X tuning to optimize time alignment, frequency and phase response for the crossover network
- D-CONTOUR intelligent multi-band dynamics processor
- DSP protection for maximum output and component longevity
- Custom designed transducers
- High-Efficiency Class-D Amplifiers
- Onboard 2-Ch Mixer

- Speaker Type: 2-way bi-amp powered loudspeaker, bass-reflex
- Frequency Response (-10dB): 44Hz - 20kHz
- Coverage Pattern: 90° x 60°
- Max SPL (Peak): 131dB SPL
- LF Transducer: 15" cone, 2.5" voice coil, ferrite magnet
- HF Transducer: 1.4" compression driver with 1" throat, ferrite magnet
- Crossover Frequency: 1.8kHz (FIR-X tuning)
- Amplifier Type: Class-D
- Amplifier Power (LF): 800W (Dynamic), 400W (Continuous)
- Amplifier Power (HF): 200W (Dynamic), 65W (Continuous)
- Input Connectors: INPUT1: Combo x1, INPUT2: Combo x1 + RCA pin x2 (Unbalanced)
- Output Connectors: XLR3-32 x1 (CH1 Parallel Through or CH1+CH2 Mix)
- Power Supply: 100V, 100-120V, 220-240V, 110/127/220V (Brazil), 50/60Hz
- Power Consumption (Idle): 18W
- Enclosure Material: Plywood
- Grille Material: Metal
- Mounting Options: Dual-angle pole sockets (0° or -7°), M10 eyebolt rigging points (top x2, rear x1)

Dimensions and Weight in Packaging

Base Item

  • Shipping Weight: 65.5 lbs
  • Shipping Dimensions: 30 x 22 x 20 in
  • Manufacturer Part Number (MPN): DHR15

For support or warranty questions, please contact the manufacturer:
Phone: 714-522-9011
Web: https://usa.yamaha.com/support
Yamaha DHR15 Spec Sheet
