Universal Audio 4-710D 4-Channel Microphone Preamp
Add 4 channels of Twin-Finity mic preamps to your recording studio rack! The 4-710D's hybrid signal path lets you blend solid-state clarity and tube warmth.
Overview
The Universal Audio 4-710d is a boutique quality, four-channel microphone/line preamplifier with unique tube and solid-state tone blending capabilities, perfect for a wide range of microphone and instrument sources. This versatile multi-channel preamp offers selectable 1176-style compression circuitry on each channel, plus four additional line inputs feeding eight channels of pristine analog-to-digital conversion. Building upon UA's classic analog design approach, combined with smart modern features, the 4-710d is the most flexible preamp in the UA lineup.
Learn more with this video from Universal Audio:
- Dual-path 285-volt Class-A tube and trans impedance solid-state preamps
- Phase-aligned tone-blending of tube and solid-state circuits, creamy to crunchy
- 1176-style compression circuit per preamp channel
- Eight channels of high quality 24-bit A/D conversion
- Selectable sample rates up to 192 kHz
- Digital output via dual ADAT optical and AES/EBU DB-25 connectors
- 8-channel soft limiter (switchable for all channels)
- 1-year Limited Warranty
At the core of the 4-710d are four channels of tone-blending Twin-Finity mic preamps with true-bypass 1176-style compression, including specially tuned "fast" and "slow" settings. Each of the four mic preamp channels allows for continuously variable phase-aligned tone, between a 100% tube and 100% solid-state signal path. Send and return jacks are… read more available for external processing or signal access.
The eight analog inputs are digitized via ultra-high quality 24-bit A/D converters at selectable sample rates up to 192 kHz. Digital output is available via dual ADAT lightpipe or AES/EBU DB-25 connectors, facilitating integration with most popular audio interfaces.
read less
Learn more with this video from Universal Audio:
Features:
- Four TEC Award-winning 710 Twin-Finity microphone/line preamps- Dual-path 285-volt Class-A tube and trans impedance solid-state preamps
- Phase-aligned tone-blending of tube and solid-state circuits, creamy to crunchy
- 1176-style compression circuit per preamp channel
- Eight channels of high quality 24-bit A/D conversion
- Selectable sample rates up to 192 kHz
- Digital output via dual ADAT optical and AES/EBU DB-25 connectors
- 8-channel soft limiter (switchable for all channels)
- 1-year Limited Warranty
At the core of the 4-710d are four channels of tone-blending Twin-Finity mic preamps with true-bypass 1176-style compression, including specially tuned "fast" and "slow" settings. Each of the four mic preamp channels allows for continuously variable phase-aligned tone, between a 100% tube and 100% solid-state signal path. Send and return jacks are… read more available for external processing or signal access.
The eight analog inputs are digitized via ultra-high quality 24-bit A/D converters at selectable sample rates up to 192 kHz. Digital output is available via dual ADAT lightpipe or AES/EBU DB-25 connectors, facilitating integration with most popular audio interfaces.
WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.
Specs
Preamplifiers:
- Four TEC Award-winning 710 Twin-Finity microphone/line preamps, each featuring:
- Dual-path 285-volt Class-A tube and transimpedance solid-state preamps
- Phase-aligned tone-blending of tube and solid-state circuits, creamy to crunchy
- Newly designed 1176-style compression circuit per preamp channel
- JFET Direct Input with 2.2MOhm ultra Hi-Z impedance w/auto input override
- Large backlit VU meters for flexible metering of input drive, gain level, and gain reduction
- Balanced send/return inserts (half-normalled)
- 48V phantom power
- 75 Hz low cut filter
- Polarity switch
- Monolithic balanced output stage
Analog-to-Digital Conversion:
- Eight channels of high quality 24-bit A/D conversion
- Selectable sample rates up to 192 kHz
- Digital output via dual ADAT optical and AES/EBU DB-25 connectors
- 8-channel soft limiter (switchable for all channels)
- Ultra-low jitter clock subsystem
- LED metering array with clip/hold indicators
- 75 ohms BNC work clock I/O
- Digital outputs anti-pop protection on power-up
Other specs:
o Universal voltage internal power supply
o Heavy-duty metal construction, two-space rack unit
o One year warranty including parts and labor
- Four TEC Award-winning 710 Twin-Finity microphone/line preamps, each featuring:
- Dual-path 285-volt Class-A tube and transimpedance solid-state preamps
- Phase-aligned tone-blending of tube and solid-state circuits, creamy to crunchy
- Newly designed 1176-style compression circuit per preamp channel
- JFET Direct Input with 2.2MOhm ultra Hi-Z impedance w/auto input override
- Large backlit VU meters for flexible metering of input drive, gain level, and gain reduction
- Balanced send/return inserts (half-normalled)
- 48V phantom power
- 75 Hz low cut filter
- Polarity switch
- Monolithic balanced output stage
Analog-to-Digital Conversion:
- Eight channels of high quality 24-bit A/D conversion
- Selectable sample rates up to 192 kHz
- Digital output via dual ADAT optical and AES/EBU DB-25 connectors
- 8-channel soft limiter (switchable for all channels)
- Ultra-low jitter clock subsystem
- LED metering array with clip/hold indicators
- 75 ohms BNC work clock I/O
- Digital outputs anti-pop protection on power-up
Other specs:
o Universal voltage internal power supply
o Heavy-duty metal construction, two-space rack unit
o One year warranty including parts and labor
- Dimensions and Weight in Packaging
- Base Item
- Shipping Weight: 17.25 lbs
- Shipping Dimensions: 23 x 17 x 8 in
- Manufacturer Part Number (MPN): 4-710D
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Phone: 831-440-1176
Web: https://help.uaudio.com/
Phone: 831-440-1176
Web: https://help.uaudio.com/
Reviews
Reviewers gave this product an overall rating of 4.5 out of 5 stars.
(4 ratings)
Submitted November 23, 2013 by a customer from gmail.com in Charlotte, NC
""if you have the means...GET one' - Ferris Bueller"
Verified Customer
zZounds has verified that this reviewer made a purchase from us.
This is all that and then some! I've used it on vocals, guitars bass, DRUMS and it is now my go-to pre. So many USEFUL features. I'm running 4 other pre's into the 4 1/4" ins and feeding the ADAT line to my interface for an all in one unit. The 4 inserts are sweet for adding noise gates to mics if needed or any other rack unit. The compressor is sweet...gets the job done without over doing it. The tube/Trans feature is SWEEEET! his unit made one helluva an impressive sonic change in my sound and recordings. And I DO love that UA sound! I see another in my future!
Highly recommended....U DIG...!
Musical Background:
Playing since the 70's. Producer, engineer, multi-instrument musician, technical analyst, mixing, etc, etc...
Musical Style:
rock, reggae, blues, hip-hop, country, jazz, classical, pop, Christian, R&B, funk, soul...
6 of 7 people (86%) people found this review helpful. Did you?
