- Frequency Band: Various ranges available (Q1-6: 470.2-526 MHz, R1-6: 520-576 MHz, R4-9: 552-607.8 MHz, S1-7: 606.2-662 MHz, S4-7: 630-662 MHz, S7-10: 662-693.8 MHz, U1/5: 823.2-831.8 & 863.2-864.8 MHz, V3-4: 925.2-937.3 MHz, Y1-3: 1785.2-1799.8 MHz)
- Audio Frequency Response: 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
- Dynamic Range: 134 dB
- THD: ≤ -60 dB for 1 kHz @ -3 dBfs input level
- Battery Type: 2 AA batteries 1.5 V (alkaline manganese) or BA 70 rechargeable battery pack
- Battery Life: Up to 8 hours with AA batteries, up to 12 hours with BA 70 rechargeable battery pack
- Operating Range: Up to 328 ft (100 m) line of sight
- Modulation: Digital UHF transmission
- Frequency Stability: 600 kHz equidistant channel spacing
- Antenna Type: Internal
- Power Requirements: 2.0 - 4.35 V, < 300 mA current consumption
- Sync Method: Bluetooth Low Energy via Smart Assist App
- Channels: Up to 90 channels simultaneously, 2,240 selectable frequencies
- Latency: 1.9 ms

Dimensions and Weight in Packaging

Band Q1-6 (470.2 - 526 MHz)

• Shipping Weight: 1 lbs
• Shipping Dimensions: 14 x 3 x 3 in
• Manufacturer Part Number (MPN): 508790

Band R1-6 (520 - 576 MHz)

• Shipping Weight: 1 lbs
• Shipping Dimensions: 14 x 3 x 3 in
• Manufacturer Part Number (MPN): 508791

Band R4-9 (552 - 607.8 MHz)

• Shipping Weight: 1 lbs
• Shipping Dimensions: 14 x 3 x 3 in
• Manufacturer Part Number (MPN): 508792

Consumer Alert

Most users do not need a license to operate this wireless system. Nevertheless, operating this system without a license is subject to certain restrictions: the system may not cause harmful interference; it must operate at a low power level (not in excess of 50 milliwatts); and it has no protection from interference received from any other device. Purchasers should also be aware that the FCC is currently evaluating use of wireless systems, and these rules are subject to change. For more information, call the FCC at 1-888-CALL-FCC (TTY: 1-888-TELL-FCC) or visit the FCC's website at www.fcc.gov/cgb/wirelessmicrophones

NOTE: None of the wireless systems we carry are capable of violating the FCC guidelines stated above. We are presenting this information as a matter of legally required disclosure.
