Roland TR-8S Rhythm Performer Drum Machine

- User Drum Kit: 128
- User Patterns: 128
- Step Sequencer:
- 11 instrument parts and 1 exclusive part for trigger out
- 16 steps per 1 measure
- 8 (A - H) variations per 1 pattern
- 2 Fill-in patterns per 1 pattern
- NST tone: Tone can be assigned to each 11 instrument parts freely
- BASS DRUM: 11 ACB tones
- SNARE DRUM: 8 ACB tones
- TOM: 15 ACB tones
- RIM SHOT: 3 ACB tones
- HAND CLAP: 5 ACB tones
- HI HAT: 8 ACB tones
- CYMBAL: 8 ACB tones
- PERCUSSION: 23 ACB tones
- PRESET SAMPLE: 150 tones or greater
- USER SAMPLE (imported form SD CARD for playback): Available format: WAV, AIFF
- Total time for all samples: Approximately 600sec (at 44.1kHz, mono)
* The maximum length of a single audio file that can be imported is approximately 180 seconds (at 44.1kHz).
- Effects:
INST FX: THRU, HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, COMPRESSOR, DRIVE, COMP+DRV, CRUSHER
REVERB: AMBI, ROOM, HALL1, HALL2, PLATE, MOD
DELAY: DLY, PAN, TAPE ECHO
MASTER FX: HPF, LPF, LPF/HPF, H BOOST, L BOOST, L/H BOOST, ISOLATOR, TRANSIENT, TRANSIENT2, COMPRESSOR, DRIVE, OVERDRIVE, DISTORTION, FUZZ, CRUSHER, PHASER, FLANGER, SBF, NOISE
Other: SIDE CHAIN (for EXT IN), SCATTER (as one of AUTO FILL IN function)
- Display:
- 16 characters, 2 line (backlit LCD)
- 7 segments, 4 characters (LED)
- External Storage: SD Card (SDHC supported) for backup/restore function and import sample data
- Connectors:
- PHONES jack: Stereo 1/4-inch phone type
- MIX OUT (L/MONO, R) jacks: 1/4-inch TRS phone type
- ASSIGNABLE OUT/TRIGGER OUT(1 - 6) jacks: 1/4-inch phone type
- EXT IN (L/MONO, R) jacks: 1/4-inch phone type
- TRIGGER OUT jack: Miniature phone type
- MIDI (IN, OUT) connectors:
- USB port: USB type B (Audio, MIDI)
- DC IN jack
- Power Supply: AC adaptor
- Current Draw: 2,000 mA
- Dimensions (W x D x H): 409 x 263 x 58 mm / 16-1/8 x 10-3/8 x 2-5/16 inches
- Weight: 2.1 kg /4 lbs 11 oz
- Accessories:
- AC adaptor
- Owner's manual
- Leaflet "USING THE UNIT SAFELY"
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 8.25 lbs
Shipping Dimensions: 22 x 14 x 5 in
Manufacturer Part Number (MPN): TR-8S
with Gator Bag
Shipping Weight: 11.25 lbs
If you have additional warranty questions, please contact the manufacturer at 323-890-3700
