The SUB 15-AX is a portable 15" high-power active subwoofer for live sound applications with fully featured processing, a color touch panel, and remote control via Bluetooth(R). The combination of a latest-generation transducer with a powerful Class-D amplifier delivers sound pressure levels up to 133 dB with exceptional clarity and headroom. SUB AX subwoofers are designed specifically for small to mid-sized venues and ideal for portable applications. SUB 15-AX is the ideal complement for 10" or 12" woofer-size loudspeakers; it centralizes speaker management inside the subwoofer, providing dual crossovers, 8-band EQs, routing, delays, cardioid configurations, and recallable crossover presets. The polyurea-coated all-wood cabinet features a sealed Powercon True1 Top connector.

Features:

- 2200 Watt Class-D Amplifier
- 133 dB MAX SPL
- 15" Woofer, bass reflex housing
- Digital Crossover w/ Presets
- Multi-ply hardwood polyurea-coated
- LiveRemote App
- Dual XLR/TRS combo Input + Link, Dual XLR Xover Out
- Bass Motion Control excursion management
- Powercon True1 Top Sealed AC Connector

ACOUSTICAL SPECIFICATIONS
- Frequency Response: 35 Hz / 120 Hz
- Max SPL: @ 1m 133 dB
TRANSDUCERS
- Woofer: 15", 3.0" v.c
INPUT/OUTPUT SECTION
- Input signal: balanced/unbalanced
- Input connectors: Combo XLR/Jack
- Output connectors: XLR
- Input sensitivity: -2 dBu/+4 dBu
PROCESSOR SECTION
- Protections: Thermal
- Limiter: Soft Limiter
- Controls: Encoder for Volume control and data entry. Touch Screen for parameter management and monitor.
POWER SECTION
- Total Power: 2200 W Peak, 1100 W RMS
- Cooling: Convection
- Connections: Powercon TRUE1 TOP IN/OUT
STANDARD COMPLIANCE
- Safety: agency CE compliant
PHYSICAL SPECIFICATIONS
- Handles: 1 handle per side
- Pole: mount/Cap Yes
- Color: Black, White
SIZE
- Height: 590 mm / 23.23 inches
- Width: 420 mm / 16.54 inches
- Depth: 590 mm / 23.23 inches
- Weight: 26 kg / 57.32 lbs
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 82.25 lbs
Shipping Dimensions: 25 x 25 x 19 in
Manufacturer Part Number (MPN): 13000832
