- Conguration: Multi-purpose, 2-way powered loudspeaker
- LF Transducer: 12" Woofer
- HF Transducer: 1.4" titanium diaphragm compression driver
- Frequency Response (-6 dB): 50 Hz - 20 kHz
- Frequency Range (-10 dB): 45 Hz - 20 kHz
- Nominal Coverage Angle:
- Maximum Rated SPL1: 132 dB @ 1 M, peak 126 dB @ 1 M, continuous
- Amplifier: Class D
Peak: 1800 W (LF), 225 W (HF)
- Cooling: Low-noise, variable speed fan
- Controls: Power, 3 x Level, Rotary encoder (push), 2 x selection buttons
Indicators - Monochrome LCD Display 1.75" x 1"
- 2 x Power LED (front and rear)
- 3 x Input Signal LED
- Input A Mic selected LED
- Input B Hi-Z selected LED Limiter active LED
Connectors - 2 x locking XLR/F 1/4" combo (Mic/Line Input and Hi-Z/Line Input
- 1 x 3.5 mm TRS (Stereo Input)
- 2 x XLR/M (Loop-thru Output)
- 1 x XLR/M (Mix Output)
- 1 x locking IEC power connector
Additional Specs - AC Power Input: Universal power supply 100 - 240 VAC, 50 - 60 Hz
- AC Power Consumption 1/8th Power: 100 VAC, 2.1 A / 120 VAC, 1.9 A / 240 VAC, 1.1 A
- Enclosure Enclosure: Impact Resistant ABS
- Attachment Points: 2 x M10 threaded inserts plus Pull-Back
- Color: Black
- Grille: 18 Gauge powered coated steel, internal cloth lining
- Dimensions (HxWxD): 23.7 x 14 x 13.8 in
- Net Weight: 39 lbs
- Dimensions and Weight in Packaging
- Single Speaker
-
Shipping Weight: 48.5 lbs
-
Shipping Dimensions: 26 x 19 x 19 in
-
Manufacturer Part Number (MPN): K12.2-NA
- Pair
-
Shipping Weight: 97 lbs
- Pair, with Totes
-
Shipping Weight: 105.5 lbs
- Pair, with Speaker Pack
-
Shipping Weight: 124.5 lbs
