Ortofon Concorde Pro S DJ Turntable Cartridge

No longer available at zZounds
This is a carousel with one large image and a track of thumbnails on the left side. Select any of the thumbnail buttons to change the main image. You may also use the left and right arrow keys to navigate between images.
Ortofon Concorde Pro S DJ Turntable Cartridge, Main
Ortofon Concorde Pro S DJ Turntable Cartridge, Main
zZounds Gear Experts Say...
Designed with gigging DJs in mind, the Pro S DJ cartridge is built for excellent sound quality and rock-solid tracking stability.

The Ortofone Concorde Pro S DJ turntable cartridge is perfect for beginners on the DJ scene who want to start off with decent, but not too expensive equipment. The Pro S has a spherical diamond stylus which minimizes scratching and a solid cantilever which can survive hectic activity at the turntable. No matter what the application, the Pro S provides remarkable versatility for virtually any setting.

The sound quality is absolutely not to worry about. The Pro S is a consistent performer and a fine all-a-rounder!

- Output voltage at 1000Hz, 5cm/sec.: 5 mV
- Channel balance at 1kHz: 2 dB
- Channel separation at 1kHz: 20 dB
- Channel separation at 15 kHz: 15 dB
- Frequency range at -3dB: 20-20.000 Hz
- Frequency response: 20-18.000 Hz +/- 2 dB
- Tracking ability at 315 Hz at recommended tracking force: 70 micrometers
- Compliance, dynamic lateral: 7 micro m/m N
- Stylus type: Spherical
- Stylus tip radius: R 26 micrometers
- Tracking force range: 3,0-5,0 g (30-50 mN)
- Tracking force recommended: 4,0 g (40 mN)
- Tracking angle: 20 degrees
- Internal impedance, DC resistance: 750 ohm
- Internal inductance: 450 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacitance: 200-600 pF
- Cartridge weight: 18.5 g
- Replacement stylus unit: Pro S
