Mesa/Boogie Vintage Split Back 4x12 Slant Guitar Speaker Cabinet




Overview
Blast from the past! We're excited to announce the return of Boogie Split Back 2x12 and 4x12 Cabinets that propelled some of the biggest sounds in 80s rock. Recorded and toured by the decade's fiercest and finest, these innovative cabinets presented the best attributes of both open and closed-back designs in one convenient package. After an almost three-decade hiatus, we are resuming production of these extraordinary Boogie cabs. And they perfectly complement our Mark IIC+ and Dual Rectifier Solo Heads!
- Pristine, airy, clean performance of open-back cabs
- Percussive, tight low end of a closed-back cab
- 2 proprietary Celestion C90 drivers in an open chamber
- 2 Celestion Vintage 30s in a lower sealed chamber
- Iconic chugging low end & classic Brit-flavored "mid scoop"
- Main Input, Parallel Output, & a pair of Split Mode Inputs
- Removable casters on Track-Loc guide plates make transport & setup easy
- Tough Bronco Tolex vinyl exterior
- Slip cover included
Delivering the pristine, airy, clean performance of open-back cabs with an open chamber on top and the percussive, tight low end of a closed-back cab with a sealed chamber below, the Boogie Split Back design covers well and elevates the broad spectrum of sounds guitarists need without the need for separate dedicated cabinets.
Tough Bronco Tolex vinyl and hand-formed leather corners cover the exterior of the void-free marine-grade… read more Baltic birch plywood shell, forming a strong and toneful dwelling for the proprietary UK-built Celestion drivers. The unique and sturdy expanded metal Grille protects and beautifies them, while the removable Casters on their Track-Loc guide plates make transport and setup a push-button affair.
The 4x12 Split Back utilizes two C90s on top in the open chamber and two proprietary Celestion Vintage 30s in the lower sealed chamber for iconic chugging low end, classic Brit-flavored "mid scoop" and sweet harmonic-laden top end. Like all MESA cabinets wired standard at 8 Ohms, the rear Jack Plate features the main INPUT and a PARALLEL output jack (when adding an additional 8 Ohm Cab, impedance becomes a 4 Ohm total load). The 4x12 also features a pair of SPLIT Mode Inputs, offering the option of separating the left and right halves of the cabinet for Stereo operation (@ 4 Ohms per side).
read less
Features:
- Innovative design combines the best of open & closed-back cabinets- Pristine, airy, clean performance of open-back cabs
- Percussive, tight low end of a closed-back cab
- 2 proprietary Celestion C90 drivers in an open chamber
- 2 Celestion Vintage 30s in a lower sealed chamber
- Iconic chugging low end & classic Brit-flavored "mid scoop"
- Main Input, Parallel Output, & a pair of Split Mode Inputs
- Removable casters on Track-Loc guide plates make transport & setup easy
- Tough Bronco Tolex vinyl exterior
- Slip cover included
Delivering the pristine, airy, clean performance of open-back cabs with an open chamber on top and the percussive, tight low end of a closed-back cab with a sealed chamber below, the Boogie Split Back design covers well and elevates the broad spectrum of sounds guitarists need without the need for separate dedicated cabinets.
Tough Bronco Tolex vinyl and hand-formed leather corners cover the exterior of the void-free marine-grade… read more Baltic birch plywood shell, forming a strong and toneful dwelling for the proprietary UK-built Celestion drivers. The unique and sturdy expanded metal Grille protects and beautifies them, while the removable Casters on their Track-Loc guide plates make transport and setup a push-button affair.
The 4x12 Split Back utilizes two C90s on top in the open chamber and two proprietary Celestion Vintage 30s in the lower sealed chamber for iconic chugging low end, classic Brit-flavored "mid scoop" and sweet harmonic-laden top end. Like all MESA cabinets wired standard at 8 Ohms, the rear Jack Plate features the main INPUT and a PARALLEL output jack (when adding an additional 8 Ohm Cab, impedance becomes a 4 Ohm total load). The 4x12 also features a pair of SPLIT Mode Inputs, offering the option of separating the left and right halves of the cabinet for Stereo operation (@ 4 Ohms per side).
Specs
ORIENTATION: Split Back 4x12
PRODUCT SERIES: Boogie Cabinet Series
BUILD LOCATION: Built In Petaluma, CA, with the World's Finest Materials
CABINET MATERIAL: Marine Grade, Baltic Birch
STANDARD FINISH OPTIONS: Black Bronco Vinyl, Black Metal Grille, Black Handle & Corners
CUSTOM FINISH OPTIONS: See Custom Finish Gallery
STYLE/TYPE: Split Back Design
SPEAKER(S) & MOUNTING POSITION: 2x Celestion C90 (Top) / 2x Celestion V30 (Bottom), Front Mounted, Top and Bottom
WATTAGE: 300 Watts
MONO OR MONO + STEREO INPUT: Mono and Stereo (Splits Left and Right)
CABINET IMPEDANCE: 8 Ohm (2x 4 Ohm With Stereo Input)
TRANSPORT ASSISTANCE: Track-Loc Removable Casters
ADDITIONAL FEATURES: Paralleled Mono Output
ACCESSORIES: Included - Fitted Slipcover
WEIGHT: 101 lbs. (45.81 kg)
HEIGHT: 32" (81.28 cm)
WIDTH: 26 7/8" (68.26 cm)
DEPTH: 15 1/2" (39.37 cm)
PRODUCT SERIES: Boogie Cabinet Series
BUILD LOCATION: Built In Petaluma, CA, with the World's Finest Materials
CABINET MATERIAL: Marine Grade, Baltic Birch
STANDARD FINISH OPTIONS: Black Bronco Vinyl, Black Metal Grille, Black Handle & Corners
CUSTOM FINISH OPTIONS: See Custom Finish Gallery
STYLE/TYPE: Split Back Design
SPEAKER(S) & MOUNTING POSITION: 2x Celestion C90 (Top) / 2x Celestion V30 (Bottom), Front Mounted, Top and Bottom
WATTAGE: 300 Watts
MONO OR MONO + STEREO INPUT: Mono and Stereo (Splits Left and Right)
CABINET IMPEDANCE: 8 Ohm (2x 4 Ohm With Stereo Input)
TRANSPORT ASSISTANCE: Track-Loc Removable Casters
ADDITIONAL FEATURES: Paralleled Mono Output
ACCESSORIES: Included - Fitted Slipcover
WEIGHT: 101 lbs. (45.81 kg)
HEIGHT: 32" (81.28 cm)
WIDTH: 26 7/8" (68.26 cm)
DEPTH: 15 1/2" (39.37 cm)
- Dimensions and Weight in Packaging
- Base Item
- Shipping Weight: 125 lbs
- Shipping Dimensions: 41 x 34 x 18 in
- Manufacturer Part Number (MPN): 0.B412V.SL.AM.FC
