Mackie 2404VLZ4 24-Channel USB Mixer

open zoom image for Mackie 2404VLZ4 24-Channel USB Mixer, New, Left

open zoom image for Mackie 2404VLZ4 24-Channel USB Mixer, New, Rear

open zoom image for Mackie 2404VLZ4 24-Channel USB Mixer, New, Right

open zoom image for Mackie 2404VLZ4 24-Channel USB Mixer, New, Side

Mackie 2404VLZ4 24-Channel USB Mixer, New, Main

Mackie 2404VLZ4 24-Channel USB Mixer, New, Front

Mackie 2404VLZ4 24-Channel USB Mixer, New, Left

Mackie 2404VLZ4 24-Channel USB Mixer, New, Rear

Mackie 2404VLZ4 24-Channel USB Mixer, New, Right

Mackie 2404VLZ4 24-Channel USB Mixer, New, Side

zZounds Gear Experts Say...

Build live mixes with this Mackie console's dedicated channel and subgroup compression -- then record the mix to your laptop over the built-in USB interface.

Overview

The 24-channel 2404VLZ4 features the proven performance of Mackie's Onyx mic preamps in a high-headroom/low-noise 4-bus design with a feature set perfect for live sound.

Learn more about the Mackie VLZ4 Series:

The 2404VLZ4 features dual 32-bit RMFX+ effects processors, each with 24 effects including tap delay. Plus, compression on dedicated channels and subgroups allows for simple, sweet dynamic control. There's even 4x2 USB connectivity for flexible recording of the show. And, of course, Mackie's legendary "Built-Like-A-Tank" construction delivers years of reliable use under the most strenuous conditions. The 2404VLZ4 is the premium compact FX mixer solution for anybody serious about performance in a design that's flexible, rugged and professional.

Check out this video from the Mackie MixBusters:

WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

Specs

- Mixer Type: 24-Channel 4-Bus FX Mixer with USB
- Total Channels: 24
- Mono Channels: 20
- Stereo Channels: 2
- Mic Preamps: 20 Onyx mic preamps
- Phantom Power: Yes
- Channel EQ: 3-band EQ with sweepable midrange (mono channels), 4-band EQ (stereo channels)
- Aux Sends: 6
- Subgroups: 4
- Main Outputs: XLR and 1/4" balanced/unbalanced
- Other I/O: 20 line inputs with inserts, aux sends, stereo returns, subgroup outputs with inserts
- Digital Interface: 4x2 USB interface
- Bit Depth: 24-bit
- Frequency Response: +0, -1 dB, 20 Hz to 50 kHz
- Total Harmonic Distortion (THD): <0.001% (Mic in to insert send), <0.005% (Mic in to main out)
- Signal-to-Noise Ratio (SNR): 91.0 dB (Main mix fader at unity, channel faders down, ref +4 dBu)
- Built-in Effects: Dual 32-bit RMFX+ processors with 24 effects including reverbs, choruses, and tap delay
- Power Requirements: 100-240V, 50-60Hz
- Power Consumption: 55W

Dimensions and Weight in Packaging

Base Item

Shipping Weight: 38.5 lbs
Shipping Dimensions: 34 x 23 x 11 in
Manufacturer Part Number (MPN): 2040769-00

Open Box (Like New)

Shipping Weight: 38.5 lbs
Shipping Dimensions: 34 x 23 x 11 in
Manufacturer Part Number (MPN): 2040769-00

Documents and Manuals

For support or warranty questions, please contact the manufacturer:
Phone: 800-898-3211
Email: support@mackie.com
Web: https://mackie.com/en/support/contact

Reviews

(1 ratings)

Submitted April 11, 2016 by Nicholas DeWolfe in Rocky Mount, NC

"Amazing Board!"

Overall:

(see rating details)

Verified Purchaser zZounds has verified that this reviewer purchased this specific product from us.

Was hoping for more than 4 channels of USB input, but after playing around with the board and learning how to subgroup everything this board is the bees knees! You cannot make this board clip any kind of recording no matter how loud you get, the preamps are the real deal. Don't be fooled by the fact that it's an analogue, it's still a powerful piece of machine! Bought this board for a recording studio I run and it has practically already paid for itself and then some! All my clients can't get over how good even the rough mixes sound! MACKIE ALL DAY!
