Lexicon IO22 USB 2.0 Audio Recording Interface
No longer available at zZounds
zZounds Gear Experts Say...
Capture two microphones or instruments at 96 kHz/24-bit resolution, through high-performance dbx preamps on the Lexicon IO22 USB audio interface.
Overview
No artist likes to be told what to do - what tools to use and what tools you cant use. Lexicon understands your passion and it inspires innovation. Brilliantly designed, the Lexicon IO Desktop Recording Series is compatible with any DAW, including Pro Tools 9 and 10. Now this innovative hardware design meets the software capability of any creative passion.
Featuring newly designed dbx 60V high-voltage, ultra-low noise mic preamps on both channels, the IO22 is more than equipped to provide professional recordings that keep your music sounding its best. The preamps run on a high-voltage supply to guarantee stability and provide you with a superior recording across a wide dynamic range. Performance driven A/DD/A converters ensure pristine 24-bit/96kHz audio to capture every subtle detail of your performance.
The IO22 can record two tracks at once and includes 2 combi-jack mic/line inputs with +48V phantom power, 2 TRS balanced line outputs, a hi-Z instrument input, a 1/4-inch high power headphone output, and MIDI I/O. Dedicated knobs and meters offer easy access to input and output levels and locking combi-jacks make sure that a connection is not lost in the middle of a performance.
- 44.1kHz to 96kHz sample rates, 24-bit resolution
- Pantheon II VST/AU reverb plug-in with 6 legendary Lexicon reverbs
- dbx 60V high-voltage, ultra-low noise microphone preamps
- Superior sonic performance
- 2 analog combi-jacks for mic/line inputs
-… read more 2 analog 1/4-inch TRS balanced outputs
- Zero latency monitoring
- Low latency ASIO drivers
- Streamlined monitor form factor puts all recording controls at your fingertips
- Separate level meters and gain control per channel
- 1 side panel 1/4-inch instrument input
- 1 side panel headphone output with dedicated volume adjustment
- MIDI in and out read less
Featuring newly designed dbx 60V high-voltage, ultra-low noise mic preamps on both channels, the IO22 is more than equipped to provide professional recordings that keep your music sounding its best. The preamps run on a high-voltage supply to guarantee stability and provide you with a superior recording across a wide dynamic range. Performance driven A/DD/A converters ensure pristine 24-bit/96kHz audio to capture every subtle detail of your performance.
The IO22 can record two tracks at once and includes 2 combi-jack mic/line inputs with +48V phantom power, 2 TRS balanced line outputs, a hi-Z instrument input, a 1/4-inch high power headphone output, and MIDI I/O. Dedicated knobs and meters offer easy access to input and output levels and locking combi-jacks make sure that a connection is not lost in the middle of a performance.
Features:
- USB 2.0 Desktop Recording Studio- 44.1kHz to 96kHz sample rates, 24-bit resolution
- Pantheon II VST/AU reverb plug-in with 6 legendary Lexicon reverbs
- dbx 60V high-voltage, ultra-low noise microphone preamps
- Superior sonic performance
- 2 analog combi-jacks for mic/line inputs
-… read more 2 analog 1/4-inch TRS balanced outputs
- Zero latency monitoring
- Low latency ASIO drivers
- Streamlined monitor form factor puts all recording controls at your fingertips
- Separate level meters and gain control per channel
- 1 side panel 1/4-inch instrument input
- 1 side panel headphone output with dedicated volume adjustment
- MIDI in and out read less
Specs
- Microphone Inputs: Female XLR Pin 2 Hot
- Input Impedance: 3kOhm balanced
- Phantom Power: +48 Volts
- Maximum gain: +58 dB
- E.I.N. (at max gain): -125 dBu @ 58dB gain typical (150Ohm source) -129 dBu @ 58dB gain typical A-weighted (150Ohm source)
- Maximum Input Level: +21 dBu at minimum gain
- Frequency Response: +0/-1 dB, 20Hz - 20kHz
- THD+N: <0.006%, 20Hz - 20kHz (mic input to main output) 0 dBu input level, Input knobs at 11 o'clock; <0.003%, 1kHz, +5 dBu input level, Input knobs at minimum, Output knob at max
- Line Inputs: 1/4" TRS balanced or unbalanced
- Input Impedance: 20kOhm balanced, 13kOhm unbalanced
- Maximum Input Level: +32 dBu
- Frequency Response: +0/-1.5 dB, 20Hz - 20kHz (reference 1kHz)
- THD+N: <0.004%, 20Hz - 20kHz (line input to main output) 0 dBu input level, Input knob at 12 o'clock, Output knob at max
- Instrument Input: 1/4" TS unbalanced
- Input Impedance: 1MOhm
- Maximum Input Level: +13 dBu
- Frequency Response: +0/-2 dB, 20Hz - 20kHz (instrument input to main output)
- THD+N: <0.004%, 20Hz - 20kHz, 0 dBu input level, Input knob at 10 o'clock, Output knob at max
- Line Outputs: 1/4" TRS balanced or unbalanced
- Level: >+18 dBu maximum
- Impedance: 32Ohm Balanced, 16Ohm Unbalanced
- Headphone Output: 1/4" stereo jack 350mW per channel at 50Ohm
- MIDI Interface: 5 pin DIN connectors for MIDI in and MIDI out (5 volt signal)
- Sample Rate: 44.1, 48, 88.2, or 96 kHz (determined by computer application)
Dynamic Range:
- A/D (24 Bit) 108 dB typical, A-weighted, 20Hz - 20kHz (44.1 kHz sample rate)
- D/A (24 Bit) 110 dB typical, A-weighted, 20Hz - 20kHz
- A/D/A (24 Bit) 102 dB typical, A-weighted, 20Hz - 20kHz
Power Requirements: 12W 9VAC
- Microsoft Windows(R) 7, Vista 32 and XP SP2
- 1.8 GHz CPU or faster
- 1 GB RAM
- Display resolution 1024x768 pixels
- DVD-ROM drive
- USB 2.0
- Internet access required for software license activation
Macintosh
- Mac(R) OS X 10.4.9 or higher
- Intel(R) Multicore system (Required)
- 1 GB RAM
- Display resolution 1024x768 pixels
- DVD-ROM drive
- USB 2.0
- Internet access required for software license activation
- Input Impedance: 3kOhm balanced
- Phantom Power: +48 Volts
- Maximum gain: +58 dB
- E.I.N. (at max gain): -125 dBu @ 58dB gain typical (150Ohm source) -129 dBu @ 58dB gain typical A-weighted (150Ohm source)
- Maximum Input Level: +21 dBu at minimum gain
- Frequency Response: +0/-1 dB, 20Hz - 20kHz
- THD+N: <0.006%, 20Hz - 20kHz (mic input to main output) 0 dBu input level, Input knobs at 11 o'clock; <0.003%, 1kHz, +5 dBu input level, Input knobs at minimum, Output knob at max
- Line Inputs: 1/4" TRS balanced or unbalanced
- Input Impedance: 20kOhm balanced, 13kOhm unbalanced
- Maximum Input Level: +32 dBu
- Frequency Response: +0/-1.5 dB, 20Hz - 20kHz (reference 1kHz)
- THD+N: <0.004%, 20Hz - 20kHz (line input to main output) 0 dBu input level, Input knob at 12 o'clock, Output knob at max
- Instrument Input: 1/4" TS unbalanced
- Input Impedance: 1MOhm
- Maximum Input Level: +13 dBu
- Frequency Response: +0/-2 dB, 20Hz - 20kHz (instrument input to main output)
- THD+N: <0.004%, 20Hz - 20kHz, 0 dBu input level, Input knob at 10 o'clock, Output knob at max
- Line Outputs: 1/4" TRS balanced or unbalanced
- Level: >+18 dBu maximum
- Impedance: 32Ohm Balanced, 16Ohm Unbalanced
- Headphone Output: 1/4" stereo jack 350mW per channel at 50Ohm
- MIDI Interface: 5 pin DIN connectors for MIDI in and MIDI out (5 volt signal)
- Sample Rate: 44.1, 48, 88.2, or 96 kHz (determined by computer application)
Dynamic Range:
- A/D (24 Bit) 108 dB typical, A-weighted, 20Hz - 20kHz (44.1 kHz sample rate)
- D/A (24 Bit) 110 dB typical, A-weighted, 20Hz - 20kHz
- A/D/A (24 Bit) 102 dB typical, A-weighted, 20Hz - 20kHz
Power Requirements: 12W 9VAC
Computer System Recommendations
Windows- Microsoft Windows(R) 7, Vista 32 and XP SP2
- 1.8 GHz CPU or faster
- 1 GB RAM
- Display resolution 1024x768 pixels
- DVD-ROM drive
- USB 2.0
- Internet access required for software license activation
Macintosh
- Mac(R) OS X 10.4.9 or higher
- Intel(R) Multicore system (Required)
- 1 GB RAM
- Display resolution 1024x768 pixels
- DVD-ROM drive
- USB 2.0
- Internet access required for software license activation
