Gunstreet GSWH-SL-STRAT-C5WCCT Wiring Harness

zZounds Gear Experts Say...
Upgrade the tone of your Strat quickly and easily! This Gunstreet solderless wiring harness works with Strats featuring an HSS or HSH configuration.

Do you have scratchy pots, dead spots, or controls that just feel in nice terms really weird? Enter the Gunstreet solderless wiring system! This premium solderless harness not only enhances your sound quality with top-notch components, it also improves the feel, performance, and response of your instrument. You will also get to enjoy the switchable flexibility of two distinct volume voicing options, giving you total control over your instrument's sonic character.

Thanks to the rock-solid solderless design, the hard part is already handled! The Gunstreet solderless harnesses feature a unique adjustable design that fits more instruments than others offering a similar setup and creates for a rapid, hassle-free installation. This means you can get back to those sick riffs as quickly as possible!

Whether you realize it or not, your instrument's electronics are a massive part of your playing experience, and now there is no reason you can't experience the best. Upgrade your tone today and experience the difference!

Gunstreet takes their quality very seriously. That's why they only use real trained technicians who hand build each kit, and then send it through their proprietary testing process where they audio test every control, switch, or option to make sure that when you received the item its free of any hums, crackles, or pops!

How the VVC works:
Down: Saves more low end as you are using the Volume
UP: Saves more High end as you are using the Volume

How the BT Switch (Bridge read more Tone) works:
Down: Standard setup of no tone control on your bridge pickup
UP: Tone 1 can now be used in any positions the Bridge pickup is "ON"

How the Coil switching works:
4.Classic Cut: Where Gunstreet cut out one of the coils giving you a "True single coil sound"
5.P90: This flavors the Single coil sound to be close to a P90.
6.Sparkle Tap: This gives you a sparkly, twangy single coil sound.

Features:

- Designed for both HSS, and HSH Strats
- 3 Distinct Single Coil sounds.
- Two distinct volume voicing options
- Option to add a tone control to the 1st switching position
- Hassle-free installation
read less

- Pot Shaft Diameter: 3/8" (9.52MM)
- Pot Taper style: Custom Audio taper
- Pot Shaft Length: 3/8" (9.52MM)
- Pot Knob Pattern: 18 tooth Coarse
- Pot Value: 500k +/-17% Volume, 250k +/-17% Tones
- Required Cavity Depth for Push pull: 1 1/16" (26.98mm)
- Switch Mounting hole diameter: 1/2" (12.70mm)
- Switch Thread height: 7/32" (5.56mm)
- Switch Tip Threading: 8-32
- Capacitor Values: 0.022uf -/+10%
- Mono jack Required mounting hole diameter: 3/8" (9.53mm)


Requirements
Gunstreet Pots utilize an 18-tooth "coarse" knurled shaft. When replacing a kit that uses 24-tooth "fine" knurled pots, such as CTS, knob replacement will be necessary. Incorrect installing a knob can cause damage to the potentiometer
This kit is compatible only with pickups featuring a 4-conductor lead in the bridge position. It is not compatible with pickups that use either a braided wire, or 2-conductor lead.
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 0.5 lbs
Shipping Dimensions: 8 x 4 x 3 in
Manufacturer Part Number (MPN): GSWH-SL-STRAT-C5WCCT
