Focal Shape 40 Active Powered Studio Monitor

Get studio-reference sound from a small-footprint nearfield monitor with the Shape 40 powered speaker -- the most compact model in Focal's professional line.

Overview

The Focal Shape 40 is the most compact studio monitor in the Focal Professional line, and the perfect solution for nearfield monitoring. These monitors can be used from 23" away (60cm), and they have astonishingly extended low end frequency response. Whether you have a room of less than 107ft2 (10m2), or an installation where compactness is paramount, Shape 40 is the perfect solution.

Features:

- Low tweeter directivity for a flexible listening position
- Designed without a port allowing it to be placed near a wall
- Numerous settings for optimal integration
- Accurate control, even in the very high end
- Flax sandwich cone: controlled and articulated bass, natural and detailed lower mid-range and upper mid-range registers.
- Threads for ceilling and wall mounts (fastening accessories not supplied)

WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

Specs

- System: SHAPE 40
- Frequency response: (+/-3dB) 60Hz - 35kHz
- Maximum SPL (musical signal): 102dB SPL (peak @ 1m)
- Type: XLR balanced 10kOhms
- Connectors RCA: unbalanced 10kOhms with sensitivity compensation
- Midrange and low frequency amplifier: 25W, class AB
- High frequency amplifier: 25W, class AB
- Automatic standby: Standby on After approximately 30 minutes with no signal, Standby off Signal detection > 3 mV
- Electrical supply:
- Voltages 220-240V (T500mAL / 250V fuse) or
- 100-120V (T1.6AL / 250V fuse)
- Connection: IEC plug and detachable power cord
- High pass filter:
- Adjustable Full range / 80Hz
- Bass (0 - 250Hz) Adjustable, +/-6dB
- Midrange/bass (160Hz, Q=1) Adjustable, +/-3dB
- High (4.5 - 35kHz) Adjustable, +/-3dB
- Power: On/Power Off On/off switch on rear panel
- Standby consumption: < 0.5W
- Displays and controls: LED for power on/off and standby
- Woofer: 4" (10cm) Flax Cone
- Tweeter: 1" (25mm) 'M' profile Aluminum-Magnesium
- Cabinet Construction: 0.5" (12mm) MDF
- Finish: Vinyl, real walnut and black painting
- Dimensions with four rubber feet (HxWxD): 10.1 x 6.3 x 7.9" (257 x 161 x 200mm)
- Weight: 16.1lb (5kg)

Dimensions and Weight in Packaging
Dark Walnut, Single Speaker: Shipping Weight: 13.5 lbs; Shipping Dimensions: 15 x 10 x 9 in; Manufacturer Part Number (MPN): #FOPRO-SHAPE40
