The A32pro is based on a modular hardware platform and is fully equipped with the most popular analog and digital interfaces. In addition to 32x32 studio-quality balanced analog inputs and outputs and stereo main out up to 192kHz, the A32pro offers ADAT (32x32 channels) as well as MADI (64x64 channels) -- probably the most widely used digital audio interfaces ever.

The highly integrated converter is housed in a compact 1U chassis and features 32x32 balanced analog channels output via eight d-Sub-25 connectors. They deliver studio levels up to +20dBu, individually adjustable in 1dB steps.

The sophisticated design with latest generation ESS converters, accompanied by a temperature compensated clock and jitter reduction PLL, guarantees the best crystal clear sound up to 192kHz. The A32pro is not only a converter, but thanks to its flexibility and a sophisticated routing matrix also a digital format converter for the integration of your existing and future MADI and ADAT networks.

Features:

- 32x32 balanced analog I/O channels on d-Sub25 connectors, with a maximum I/O level of +20dBu
- Individually adjustable input gain and output level of all analog I/Os
- Automatic redundant slot switching in case of signal loss of an SFP module
- 32x32 ADAT I/O channels on TOSLINK connectors
- Two independent high-end heaphone outputs with sophisticated monitoring matrix
- Balanced 1/4" TRS stereo output mirroring the red headphone output source
- 1x MADI SFP module multimode (standard… read more module)
- GPIO port with 4 I/Os for external alarm monitoring and preset switching
- Preset management with eight renamable presets
- Almost all analog and digital inputs and outputs can be routed in groups of 8 channels
