General
- Model Name: Mustang V Head
- Series: Mustang(tm)
- Amplifier Type: Solid State
- Color / Part # : Black 230-0050-000

Electronics
- Voltage: Array
- Wattage: Array
- Effects Loop: Stereo Series Effects Loop
- Inputs: One 1/4" Instrument
- Auxiliary Input: 1/8" Auxiliary Input Jack
- Headphone Jack: 1/8" Headphone Jack
- Line Out: USB port, 1/8" Headphone Jack doubles as Speaker Emulated Line Out
- Channels: One Channel with 100 Presets
- Power Handling: 150 Watts (2 x 75) Stereo
- Controls: Gain, Volume, Treble, Middle, Bass, Reverb, Master; Data Wheel; soft keys for Amp Select, Stomp Edit, Modulation Edit, Delay Edit, Reverb Edit, Utility, Save, Exit, and Tap/Tuner

Hardware
- Grill Cover Cloth: Black Textured "Carbon Tweed" Vinyl Covering with Silver Grill Cloth
- Output Impedance: 8 Ohms per side
- Amplifier Length: 10.25" (26 cm)
- Amplifier Width: 26.5" (67.31 cm)
- Amplifier Height: 10.5" (26.7cm)
- Amplifier Weight: 27 lbs. (12.2 kg)
- Effects: 12 Amp Models, 7 Stomp Effects, 11 Modulation Effects, 9 Delay Effects, and 10 Reverb Effects

Miscellaneous
Additional Comments: 12 Amp Models: '57 Deluxe(tm), '59 Bassman(r), '57 Champ(R), '65 Deluxe Reverb(r), '65 Princeton(r) Reverb, '65 Twin Reverb(r), Super-Sonic(tm), British '60s, British '70s, British '80s, American '90s, Metal 2000; 7 Stomp Effects: Overdrive, Fixed Wah, Touch Wah, Fuzz, Fuzz Touch Wah, Compressor, Simple Compressor; 11 Modulation Effects: Sine Chorus, Triangle Chorus, Sine Flanger, Triangle Flanger, Vibratone, Vintage Tremolo, Sine Tremolo, Ring Modulator, Step Filter, Phaser, Pitch Shifter; 9 Delay Effects: Mono Delay, Mono Echo Filter, Stereo Echo Filter, Multitap Delay, Ping Pong Delay, Ducking Delay, Reverse Delay, Tape Delay, Stereo Tape Delay; 10 Reverb Effects: Small Hall, Large Hall, Small Room, Large Room, Small Plate, Large Plate, Ambient, Arena, Fender '63 Spring Reverb, Fender '65 Spring Reverb
Unique Features: Guitar amp with all-new DSP platform, all new high-quality amp models and effects; 100 onboard factory and user presets; headphone output and auxiliary input; chromatic tuner; "Millennium Blackface" treatment includes carbon tweed covering and new top-loaded front control panel; USB connectivity for high-quality, low-latency audio output and interface with free Fender FUSE PC application; Fender FUSE application offers on-screen parameter control, deep editing, unlimited preset storage, online patch swapping and easy firmware upgrades; Fender FUSE community includes chat forums, preset trading, and additional content from Fender and artists; includes disc with Ableton(r) Live Lite Fender edition, AmpliTube(r) Fender LE edition and other extras, making Mustang a one-stop solution for guitarists new to digital recording, mates perfectly with Mustang V 412 Enclosure (p/n 2301400000)

Accessories
FootSwitch: Included 4-Button Footswitch (P/N 008-0996-000) for Quick Access, Preset/Bank Select, Or Effects On/Off, and Tuner; Optional Programmable 2 Button Footswitch (P/N 008-0997-000) available.
