Eminence Legend EM12 Guitar Speaker (200 Watts, 12")
Ever hear the story of the guy with the 200-watt speakers? Neither did he! And he didn't regret it: these speakers back their power up with a focused voice.
Overview
An addition to Eminence's popular Legend Series of guitar speakers is the 12", 200 watt Legend EM12. As the name suggests, the Legend Series offers classic tones from the past that have been utilized and made popular by many Eminence OEM amplifier customers since 1966. Featuring a 2.5" voice coil, 80 oz. ceramic magnet, and die-cast aluminum basket, the Legend EM12 features ultra-clean tone with big, round, punchy lows and warm, smooth mids and highs.
Take an in-depth tour of the Eminence speaker factory:
Take an in-depth tour of the Eminence speaker factory:
WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.
Specs
- Nominal Basket Diameter: 12", 305 mm
- Nominal Impedance: 8 O
- Watts: 200 W
- Resonance : 49 Hz
- Usable Frequency Range: 60 Hz - 4.9 kHz
- Sensitivity: 101.1 dB
- Magnet Weight: 80 oz.
- Gap Height: 0.375", 9.5 mm
- Voice Coil Diameter: 2.5", 64 mm
- Resonant Frequency (fs): 49 Hz
- DC Resistance (Re): 6.6 O
- Coil Inductance (Le): 0.49m H
- Mechanical Q (Qms): 7.39
- Electromagnetic Q (Qes): 0.29
- Total Q (Qts): 0.28
- Compliance Equivalent Volume (Vas): 102.31 liters / 3.61 cu.ft.
- Peak Diaphragm Displacement Volume (Vd): 0 cc
- Mechanical Compliance of Suspension (Cms): 0.26 mm/N
- BL Product (BL): 16.9 T-M
- Diaphragm Mass Inc. Airload (MMs): 40 grams
- Efficiency Bandwidth Product (EBP): 170
- Maximum Linear Excursion (Xmax): 1.27 mm
- Surface Area of Cone (Sd): 532.4 cm2
- Driver Volume Displaced: 0.09 cu.ft. / 2.55 liters
- Overall Diameter: 12.38", 314.5 mm
- Baffle Hole Diameter: 11.07", 281.2 mm
- Front Sealing Gasket: Yes
- Rear Sealing Gasket: Yes
- Mounting Holes Diameter: 0.26", 6.6mm
- Mounting Holes B.C.D.: 11.57", 293.9mm
- Depth: 5.38", 136.5 mm
- Net Weight: 16.3 lbs, 7.39 kg
- Coil Construction: Edge wound aluminum voice coil
- Coil Former: Polyimide former
- Magnet Composition: Ferrite magnet
- Core Details: Vented core
- Basket Materials: Die cast aluminum basket
- Cone Composition: Paper cone
- Cone Edge Composition: Paper cloth edge
- Dust Cap Composition: Paper dust cap
- Nominal Impedance: 8 O
- Watts: 200 W
- Resonance : 49 Hz
- Usable Frequency Range: 60 Hz - 4.9 kHz
- Sensitivity: 101.1 dB
- Magnet Weight: 80 oz.
- Gap Height: 0.375", 9.5 mm
- Voice Coil Diameter: 2.5", 64 mm
- Resonant Frequency (fs): 49 Hz
- DC Resistance (Re): 6.6 O
- Coil Inductance (Le): 0.49m H
- Mechanical Q (Qms): 7.39
- Electromagnetic Q (Qes): 0.29
- Total Q (Qts): 0.28
- Compliance Equivalent Volume (Vas): 102.31 liters / 3.61 cu.ft.
- Peak Diaphragm Displacement Volume (Vd): 0 cc
- Mechanical Compliance of Suspension (Cms): 0.26 mm/N
- BL Product (BL): 16.9 T-M
- Diaphragm Mass Inc. Airload (MMs): 40 grams
- Efficiency Bandwidth Product (EBP): 170
- Maximum Linear Excursion (Xmax): 1.27 mm
- Surface Area of Cone (Sd): 532.4 cm2
- Driver Volume Displaced: 0.09 cu.ft. / 2.55 liters
- Overall Diameter: 12.38", 314.5 mm
- Baffle Hole Diameter: 11.07", 281.2 mm
- Front Sealing Gasket: Yes
- Rear Sealing Gasket: Yes
- Mounting Holes Diameter: 0.26", 6.6mm
- Mounting Holes B.C.D.: 11.57", 293.9mm
- Depth: 5.38", 136.5 mm
- Net Weight: 16.3 lbs, 7.39 kg
- Coil Construction: Edge wound aluminum voice coil
- Coil Former: Polyimide former
- Magnet Composition: Ferrite magnet
- Core Details: Vented core
- Basket Materials: Die cast aluminum basket
- Cone Composition: Paper cone
- Cone Edge Composition: Paper cloth edge
- Dust Cap Composition: Paper dust cap
- Dimensions and Weight in Packaging
- Base Item
- Shipping Weight: 17 lbs
- Shipping Dimensions: 13 x 13 x 7 in
- Manufacturer Part Number (MPN): LEGEND EM12
Reviews
Reviewers gave this product an overall rating of 5 out of 5 stars.
(1 ratings)
Submitted December 27, 2019 by Dennis S in Flagstaff, AZ
"Ridiculous !"
Verified Customer
zZounds has verified that this reviewer made a purchase from us.
I built two 2x12 cabinet's for the spec's of these speaker's, thanks to zZounds financing I was finally able to get them " shameless plug plug plug " I had Celestion 70/80's in the cabinet's and they were decent but the Eminence EM12 blows away every speaker I have ever played , crystal clear definition regardless of the gain and volume I throw at it , I'm particularly impressed with the bass definition , No Mud ! The sound of my rig comes through with no speaker distortion , the cleans at high volume are bell like. I've played EVM'S 12L & BLS and love them but cannot justify the price , the Eminence EM12 is on par with the EVM at a better price point for me. I play Les Paul's with various high output pickups , my main amp is a Randall RG1003 boosted with a Boss Metal Zone , I also use a Marshall DSL-100 boosted with Boss DS-1 for milder and clean tones , I use the same cabinet's that I built now loaded with the EM12's , without a doubt the most satisfying speaker purchase I've ever made.
Sound
The best sounding speaker's I've ever purchased , extremely clear with no speaker breakup
Features
These are Tanks ! I like the no solder connections made for a quick plug and play , they are obviously overbuilt, I cannot say enough about the definition particularly the bass.
Ease of Use
Crystal clear even response.
Quality
These are overbuilt tanks ! They'll probably… read more outlast me.
Value
As I noted , I love the EVM12L & BLS but the price had me looking at other options , the Eminence EM12 is about 1/2 the price and for my purposes it does what I want.
Manufacturer Support
I talked to an Eminence rep several time's before purchasing , he was very helpful and patient with all my questions.
The Wow Factor
I am blown away by the EM12 , the sound is on the Mark with other's costing almost twice as much , the construction is if obvious quality, It's A Tank !
Musical Background:
I've been playing 35+yrs , build repair Guitars & Cabinet's , I have a degree in music & guitar , record play at home.
Musical Style:
I play just about everything but my main interest is Heavy Metal read less
Sound
The best sounding speaker's I've ever purchased , extremely clear with no speaker breakup
Features
These are Tanks ! I like the no solder connections made for a quick plug and play , they are obviously overbuilt, I cannot say enough about the definition particularly the bass.
Ease of Use
Crystal clear even response.
Quality
These are overbuilt tanks ! They'll probably… read more outlast me.
Value
As I noted , I love the EVM12L & BLS but the price had me looking at other options , the Eminence EM12 is about 1/2 the price and for my purposes it does what I want.
Manufacturer Support
I talked to an Eminence rep several time's before purchasing , he was very helpful and patient with all my questions.
The Wow Factor
I am blown away by the EM12 , the sound is on the Mark with other's costing almost twice as much , the construction is if obvious quality, It's A Tank !
Musical Background:
I've been playing 35+yrs , build repair Guitars & Cabinet's , I have a degree in music & guitar , record play at home.
Musical Style:
I play just about everything but my main interest is Heavy Metal read less
