Dunlop Cry Baby 535Q Mini Wah Wah Pedal

This itty-bitty version of the venerable Dunlop Cry Baby packs all the wail of the original, plus the Q control to adjust the sweep range!

The Dunlop Cry Baby Mini 535Q Wah provides the perfect balance of wah control and pedalboard-efficiency. Set the tonal character of your sound with the Range Selector, which allows you to choose one of the standard 535Q Wah's four most popular sweep ranges. With the Q control, you can shape the wah's response, from a narrow bandpass that emphasizes higher end harmonics to a wide bandpass that emphasizes lower end harmonics. If you want to a bump up to the front of the mix, just crank the Volume control and then kick the Boost switch to engage the level change. There's a handy LED next to the Boost switch that lets you know when it's active.

The Cry Baby Mini 535Q Wah comes in at half the size of the standard version, and on the inside, it sports the legendary red Fasel Inductor. If you want to save space while retaining ultimate control over your Cry Baby Wah sound, this pedal belongs on your pedalboard.

Features

- The perfect balance of wah control and pedalboard efficiency
- Four different frequency sweep ranges to set your own tonal character
- Adjustable, switchable boost allows you to step out in front of the mix
- Q control shapes wah response from narrow to wide
- Equipped with the legendary red Fasel Inductor
WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

- Input Impedance: 1MO
- Output Impedance: ~1.5K Ohm
- Signal to Noise Ratio Heel Down: 90 dBV
- Signal to Noise Ratio Toe Down: 97 dBV
- Range Selector Switch Position: (1 towards heel, 4 towards toe)
1st Position: 270Hz - 1300Hz
2nd Position: 320Hz - 1650Hz
3rd Position: 360Hz - 1840Hz
4th Position: 420Hz - 2100Hz
- Filter Gain: 15 dB
- Boost Control Range: 0.1 dB to 17 dB
- Bypass: True Hardwire
- Current Draw: 2.5 mA
- Power Supply: DC 9 volts
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 1.25 lbs
Shipping Dimensions: 6 x 4 x 4 in
Manufacturer Part Number (MPN): CBM535Q
