DAS Audio Altea-715A Powered Loudspeaker




zZounds Gear Experts Say...
As a main or monitor, the Altea-715A brings DAS quality sound to the masses, with a 15" woofer for powerful bass, tweakable DSP, and remote control via app.
Overview
The ALTEA-715A is a high-powered model from DAS Audio's ALTEA Series. It's equipped with a 1500 Wpeak Class D two-channel amplifier that provides extended bandwidth, wide dynamic range and exceptionally low distortion. Digital Finite Impulse Response (FIR) filters are used in the signal processing of the ALTEA-715A systems.
The DAScontrol interface allows users to configure voicing presets, input/output levels, EQ modes, delay and source mixing by way of a high-end 24-bit quality DSP and LCD screen on the rear of the cabinet. The remote control and monitoring APP DASlink of the ALTEA-700 series powered systems allows users to wirelessly stream music from mobile devices in high-definition stereo.
The high-performance transducers include the DAS 15FV4 loudspeaker, which provides accurate low frequency reproduction with a deep, powerful bass. High frequencies are handled by the brilliant M-28 FEM optimized compression driver with 1" exit providing exceptional performance and smooth reproduction.
- Ultra lightweight Class D amplifier with SMPS
- Stereo music streaming in high definition
- User definable 24-bit DSP with LCD screen
- 5 voicing presets: Live, Dance, Vocals, Bass Boost, & Monitor Mode
- User-definable memories
- Stackable 3-band EQ
- Standby Mode
- Rigging points
- Portable and live clubs
- Theaters and auditoriums
- Houses of worship
The DAScontrol interface allows users to configure voicing presets, input/output levels, EQ modes, delay and source mixing by way of a high-end 24-bit quality DSP and LCD screen on the rear of the cabinet. The remote control and monitoring APP DASlink of the ALTEA-700 series powered systems allows users to wirelessly stream music from mobile devices in high-definition stereo.
The high-performance transducers include the DAS 15FV4 loudspeaker, which provides accurate low frequency reproduction with a deep, powerful bass. High frequencies are handled by the brilliant M-28 FEM optimized compression driver with 1" exit providing exceptional performance and smooth reproduction.
Features:
- Multi-purpose system with monitor position- Ultra lightweight Class D amplifier with SMPS
- Stereo music streaming in high definition
- User definable 24-bit DSP with LCD screen
- 5 voicing presets: Live, Dance, Vocals, Bass Boost, & Monitor Mode
- User-definable memories
- Stackable 3-band EQ
- Standby Mode
- Rigging points
Applications:
- Concerts and corporate A/V- Portable and live clubs
- Theaters and auditoriums
- Houses of worship
Specs
- Frequency Range (-10 dB): 45 Hz - 20 kHz
- Horizontal Coverage (-6 dB): 90o
- Vertical Coverage: 60o
- Maximum Peak SPL at 1 m: 132 dB
- Nominal Amplifier Power (continuous): 750 W
- Nominal Amplifier Power (peak): 1500 W
- Input Type: Balanced
- Input Impeadance: 20 kohms
- Input Sensitivity: 1.95 V (+8 dBu)
- Audio Signal Input Connector: 2 x Female XLR
- AUX Input: 1 x 3.5 mm Mini Jack
- Audio Signal Loop Thru Connector: 1 x Male XLR
- Control:
- DASlink
- DAScontrol
- Current Draw: 230 V 1.5 A
- Enclosure: Construction Polypropylene
- Enclosure: Geometry Trapezoidal
- Rigging: M8 Rigging Points
- Color: Black
- Dimensions (H x W x D): 28 x 17.3 x 15" (710 x 440 x 380 mm)
- Net Weight: 43.0 lb (19.5 kg)
- Horizontal Coverage (-6 dB): 90o
- Vertical Coverage: 60o
- Maximum Peak SPL at 1 m: 132 dB
- Nominal Amplifier Power (continuous): 750 W
- Nominal Amplifier Power (peak): 1500 W
- Input Type: Balanced
- Input Impeadance: 20 kohms
- Input Sensitivity: 1.95 V (+8 dBu)
- Audio Signal Input Connector: 2 x Female XLR
- AUX Input: 1 x 3.5 mm Mini Jack
- Audio Signal Loop Thru Connector: 1 x Male XLR
- Control:
- DASlink
- DAScontrol
- Current Draw: 230 V 1.5 A
- Enclosure: Construction Polypropylene
- Enclosure: Geometry Trapezoidal
- Rigging: M8 Rigging Points
- Color: Black
- Dimensions (H x W x D): 28 x 17.3 x 15" (710 x 440 x 380 mm)
- Net Weight: 43.0 lb (19.5 kg)
- Dimensions and Weight in Packaging
- Base Item
- Shipping Weight: 55.5 lbs
- Shipping Dimensions: 32 x 21 x 17 in
- Manufacturer Part Number (MPN): Altea-715A
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Web: https://www.dasaudio.com/en/support/
Web: https://www.dasaudio.com/en/support/
