Boss GKC-DA Serial to 13-Pin GK Converter




zZounds Gear Experts Say...
With a Serial GK input and 13-pin GK output, this box converts Serial GK signals to the 13-pin GK format used by legacy gear like the Boss SY-1000 or GP-10.
Overview
The latest BOSS guitar synthesizer products feature the Serial GK digital interface, a newly developed connection method that delivers evolved performance over the analog 13-pin GK interface used in earlier BOSS and Roland guitar synth and modeling products. The GKC-DA GK Converter allows you to drive a 13-pin GK device such as the BOSS SY-1000 or GP-10 using the Serial GK output on a GK-5 or GK-5B Divided Pickup or the GM-800 Guitar Synthesizer.
- Serial GK input and 13-pin GK output
- Instrument input for passing normal guitar/bass pickup sounds to the 13-pin output
- Compact and rugged metal design
- The GKC-DA supports and allows you to use the following 13-pin GK products with Serial GK devices: BOSS Products - SY-1000 Guitar Synthesizer, GP-10 Guitar Processor. Roland Products - GR-55 Guitar Synthesizer and other legacy products with a 13-pin GK input
Features:
- Converts the Serial GK digital interface to the classic 13-pin analog GK interface- Serial GK input and 13-pin GK output
- Instrument input for passing normal guitar/bass pickup sounds to the 13-pin output
- Compact and rugged metal design
- The GKC-DA supports and allows you to use the following 13-pin GK products with Serial GK devices: BOSS Products - SY-1000 Guitar Synthesizer, GP-10 Guitar Processor. Roland Products - GR-55 Guitar Synthesizer and other legacy products with a 13-pin GK input
Specs
- Connectors:
- GK IN jack: 1/4-inch TRS phone type (for BGK cable only)
- GK OUT connector: 13 pins DIN type
- GUITAR IN jack: 1/4-inch phone type
- DC IN jack
- USB port: USB Micro-B (program update only)
- Nominal Input Level GUITAR IN: -10 dBu
- Maximum Input Level GUITAR IN: +16 dBu
- Input Impedance GUITAR IN: 1 M ohm
- Indicators: POWER indicator, GK CONNECT indicator
- Current Draw: 390 mA
- Power Supply: AC adaptor
- Dimensions: 115(W) x 92 (D) x 36 (H) mm, (4-17/32 (W) x 3-5/8 (D) x 1-7/16 (H) inches)
- Weight (excluding AC adaptor): 340 g, (12 oz)
- Accessories: AC adaptor, Owner's Manual, Leaflet "USING THE UNIT SAFELY"
- GK IN jack: 1/4-inch TRS phone type (for BGK cable only)
- GK OUT connector: 13 pins DIN type
- GUITAR IN jack: 1/4-inch phone type
- DC IN jack
- USB port: USB Micro-B (program update only)
- Nominal Input Level GUITAR IN: -10 dBu
- Maximum Input Level GUITAR IN: +16 dBu
- Input Impedance GUITAR IN: 1 M ohm
- Indicators: POWER indicator, GK CONNECT indicator
- Current Draw: 390 mA
- Power Supply: AC adaptor
- Dimensions: 115(W) x 92 (D) x 36 (H) mm, (4-17/32 (W) x 3-5/8 (D) x 1-7/16 (H) inches)
- Weight (excluding AC adaptor): 340 g, (12 oz)
- Accessories: AC adaptor, Owner's Manual, Leaflet "USING THE UNIT SAFELY"
- Dimensions and Weight in Packaging
- Base Item
- Shipping Weight: 1.85 lbs
- Shipping Dimensions: 10 x 9 x 6 in
- Manufacturer Part Number (MPN): GKC-DA
