Antelope Audio Zen Studio Plus Thunderbolt and USB Audio Interface
No longer available at zZounds
zZounds Gear Experts Say...
Get all the I/O, top-notch clocking, and 12 mic preamps from the Zen Studio -- PLUS Thunderbolt and USB connectivity and Antelope's complete FPGA FX library!
Overview
The Antelope Audio Zen Studio Plus is an audio interface with 12 mic pres. The Zen Studio+ features a zero latency DSP engine, AFC clocking technology, an expanding library of hardware-based FPGA effects and a protective bag.
Zen Studio+ is the successor to Antelope's first-of-a-kind professional portable interface, Zen Studio. Its extensive analog and digital connectivity, 12 world-class mic preamps and Antelope's signature clocking are now accompanied by an evolving library of hardware-based vintage effects. With both Thunderbolt and USB connectivity, Zen Studio+ is the most versatile high-end mobile recording system and capable of turning any location into a professional recording studio.
The exquisite collections of Vintage EQ's include authentically models of Lang PEQ1, BAE 1073, 1084, 1023, UK69 and many other classic British and German vintage units. Vintage Compressors begin with the life-like model of the FET76… read more and many more are soon to be available, FREE to all new and registered users of Antelope's growing line of world class interfaces.
Users can create up to four independent, realtime mixes, which are assignable to any output, including the two independent headphone outputs or the Monitor or Line outputs with Antelope's proprietary routing matrix.
Zen Studio+ is the successor to Antelope's first-of-a-kind professional portable interface, Zen Studio. Its extensive analog and digital connectivity, 12 world-class mic preamps and Antelope's signature clocking are now accompanied by an evolving library of hardware-based vintage effects. With both Thunderbolt and USB connectivity, Zen Studio+ is the most versatile high-end mobile recording system and capable of turning any location into a professional recording studio.
Reinvent your studio workflow with the growing Antelope FX library
Zen Studio+ comes with a growing arsenal of vintage FPGA-based effects, including accurately modeled EQs, compressors, guitar amps and cabinets. The key to the Zen Studio+ modeling engine is its custom FPGA chip. This proprietary technology makes the interface much faster and more powerful than competing devices. You can not only create and control multiple monitor mixes in realtime, but also employ the sound of legendary studio hardware classics, while exclusively working in-the-box.The exquisite collections of Vintage EQ's include authentically models of Lang PEQ1, BAE 1073, 1084, 1023, UK69 and many other classic British and German vintage units. Vintage Compressors begin with the life-like model of the FET76… read more and many more are soon to be available, FREE to all new and registered users of Antelope's growing line of world class interfaces.
Zen Studio+ perfectly suits every pro working on-the-go
The interface features integrated Talkback function, allowing easy and fast communication between recordings artists, the engineer and the producer. Zen Studio+ offers dedicated Re-amp outs, making it the perfect choice not only for mobile recordists and traveling artists, but for pro guitarists as well.Users can create up to four independent, realtime mixes, which are assignable to any output, including the two independent headphone outputs or the Monitor or Line outputs with Antelope's proprietary routing matrix.
Access all Zen Studio+ features via desktop & mobile apps
Zen Studio+ is fully controllable via an intuitive desktop application for PC and Mac, offering flexible signal routing and customizable presets. IOS/Android Apps offer remote control for adjusting Mic Pre gain levels from anywhere in the studio, perfect for checking mic levels right at the source instruments.Perfect sound through flawless clocking
The unbeatable clocking accuracy of Zen Studio+ is provided by Antelope's renowned 64-bit Acoustically Focused Clocking (AFC) jitter management technology. Transients will shine like never before, you'll achieve a stereo image with incomparable depth and detail. read lessSpecs
ANALOG
- Analog Inputs
-- 1 x DB25 (8 channels)
-- 4 x Mic / Line / Hi-Z on XLR combos on the front
-- 8 x Mic / Line on XLR combos on the rear
- Analog Inserts
-- 2 x Inserts on 1/4" TRS (dedicated for inputs 1, 2)
- Analog Outputs
-- 1 x DB25 (8 channels)
-- 1 x Stereo pair of Monitor outs on 1/4" TRS
-- 2 x Stereo Headphone outs on 1/4" TRS (4 channels)
-- 2 x ReAmp outs on 1/4" TRS
- D/A Monitor Converter
-- Dynamic Range: 118dB
-- THD + N: -98dB
- A/D Converter
-- Dynamic Range: 120 dB
-- THD + N: -110 dB
- D/A Converters
-- Dynamic Range: 118 dB
-- THD + N: -105 dB
- Mic Preamp
-- Gain: 0,10 - 65 dB
-- THD + N: -108 dB
DIGITAL
- Digital Inputs
-- 2 x ADAT (up to 16 channels)
- 1 x S/PDIF
- Digital Outputs
-- 2 x ADAT (up to 16 channels)
-- 1 x S/PDIF
- USB I/O
-- USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz, 24 channels I/O, Type B
- Thunderbolt I/O
-- 1 x Thunderbolt, 32 channels I/O
CLOCKING
- Word Clock Input
-- 1 x Input @ 75 Ohms 3Vpp on BNC 32 - 192kHz
Word Clock Outputs
-- 1 x Outputs @ 75 Ohms 3Vpp on BNC 32 - 192kHz
Clocking System
-- 4th Generation Acoustically Focused Clocking
-- 64-bit DDS
Oven Controlled Crystal Oscillator
- Clock Stability
-- <+/-0.02 ppm, oven controlled at 64.5C/ 148.1F
- Clock Aging
-- < 1 ppm per year
- Clock Calibration
-- < +/-0.001 ppm
- Sample Rates (kHz)
-- 32, 44.1, 48, 88.2, 96, 176.4, 192
OTHER
- Operating Temperature
-- 0-50C, 32-122F
- Weight
2 kg / 4.4 lb (approx )
- Dimensions (approx)
Width: 418 mm / 16.5"
Height: 45 mm / 1.8"
Depth: 145mm / 5.7"
- Electrical specs
- DC Universal input: 18V
- Power Consumption: 25 Watts Max
In the box
- Zen Studio+ Portable Audio interface
- Quick Start Guide
- Warranty Card
- 1 USB Cable
- 1 DC Power Adapter
- Protective Bag
- System requirements
WINDOWS
- OS: Windows 7/8/8.1/10
- Disk Space: Minimum 512 MB available disk space
- USB: 1x USB 2.0 Port
- Required USB bandwidth: 80%-90%
- CPU: Intel or AMD equivalent CPU with at least 2GHz operating frequency
- Memory (RAM): 4GB Minimum (8GB or more Recommended)
MAC
- OS X: 10.9/10.10/10.11/10.12 (Sierra Recommended)
- Disk Space: Minimum 512 MB available disk space
- USB: 1x USB 2.0/3.0 Port
- Thunderbolt: 1x Thunderbolt/USB-C Port
- Required USB bandwidth: 80%-90%
- Memory(RAM): 4GB Minimum (8GB or more recommended)
- CPU: Intel Core 2 Duo (Minimum) Intel Core i3 or higher (Recommended)
- Analog Inputs
-- 1 x DB25 (8 channels)
-- 4 x Mic / Line / Hi-Z on XLR combos on the front
-- 8 x Mic / Line on XLR combos on the rear
- Analog Inserts
-- 2 x Inserts on 1/4" TRS (dedicated for inputs 1, 2)
- Analog Outputs
-- 1 x DB25 (8 channels)
-- 1 x Stereo pair of Monitor outs on 1/4" TRS
-- 2 x Stereo Headphone outs on 1/4" TRS (4 channels)
-- 2 x ReAmp outs on 1/4" TRS
- D/A Monitor Converter
-- Dynamic Range: 118dB
-- THD + N: -98dB
- A/D Converter
-- Dynamic Range: 120 dB
-- THD + N: -110 dB
- D/A Converters
-- Dynamic Range: 118 dB
-- THD + N: -105 dB
- Mic Preamp
-- Gain: 0,10 - 65 dB
-- THD + N: -108 dB
DIGITAL
- Digital Inputs
-- 2 x ADAT (up to 16 channels)
- 1 x S/PDIF
- Digital Outputs
-- 2 x ADAT (up to 16 channels)
-- 1 x S/PDIF
- USB I/O
-- USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz, 24 channels I/O, Type B
- Thunderbolt I/O
-- 1 x Thunderbolt, 32 channels I/O
CLOCKING
- Word Clock Input
-- 1 x Input @ 75 Ohms 3Vpp on BNC 32 - 192kHz
Word Clock Outputs
-- 1 x Outputs @ 75 Ohms 3Vpp on BNC 32 - 192kHz
Clocking System
-- 4th Generation Acoustically Focused Clocking
-- 64-bit DDS
Oven Controlled Crystal Oscillator
- Clock Stability
-- <+/-0.02 ppm, oven controlled at 64.5C/ 148.1F
- Clock Aging
-- < 1 ppm per year
- Clock Calibration
-- < +/-0.001 ppm
- Sample Rates (kHz)
-- 32, 44.1, 48, 88.2, 96, 176.4, 192
OTHER
- Operating Temperature
-- 0-50C, 32-122F
- Weight
2 kg / 4.4 lb (approx )
- Dimensions (approx)
Width: 418 mm / 16.5"
Height: 45 mm / 1.8"
Depth: 145mm / 5.7"
- Electrical specs
- DC Universal input: 18V
- Power Consumption: 25 Watts Max
In the box
- Zen Studio+ Portable Audio interface
- Quick Start Guide
- Warranty Card
- 1 USB Cable
- 1 DC Power Adapter
- Protective Bag
- System requirements
WINDOWS
- OS: Windows 7/8/8.1/10
- Disk Space: Minimum 512 MB available disk space
- USB: 1x USB 2.0 Port
- Required USB bandwidth: 80%-90%
- CPU: Intel or AMD equivalent CPU with at least 2GHz operating frequency
- Memory (RAM): 4GB Minimum (8GB or more Recommended)
MAC
- OS X: 10.9/10.10/10.11/10.12 (Sierra Recommended)
- Disk Space: Minimum 512 MB available disk space
- USB: 1x USB 2.0/3.0 Port
- Thunderbolt: 1x Thunderbolt/USB-C Port
- Required USB bandwidth: 80%-90%
- Memory(RAM): 4GB Minimum (8GB or more recommended)
- CPU: Intel Core 2 Duo (Minimum) Intel Core i3 or higher (Recommended)
