Connectors
- (4) 1/4” (6.35 mm) TRS audio outputs
- (1) 1/4” (6.35 mm) TRS headphone output
- (1) 1/8” (3.5 mm) TRS headphone output
- (1) MIDI DIN Output/Thru-port
- (2) 1/4” (6.35 mm) TRS audio inputs
- (1) 1/4” (6.35 mm) TS trigger input
- (2) 1/4” (6.35 mm) TRS trigger inputs
- (1) 1/4” (6.35 mm) TRS HH pedal input
- (2) 1/4” (6.35 mm) TRS footswitch inputs
- (1) MIDI DIN Input
- (1) USB Type-B port
- (1) USB Type-A port
- (1) power adapter input
USB Drive Supported Format: FAT32
- Supported File Type: 16-bit, mono or stereo .WAV files, 44.1KHz Sample Rate
Power Adapter: 9VDC, 1,500mA
Voltage: 100–240V, 50/60Hz, 1.5A Max
Dimensions: (width x depth x height) 13.75 x 14 x 3”
Weight: 8.5 lbs.
- Dimensions and Weight in Packaging
- Base Item
-
Shipping Weight: 10.5 lbs
-
Shipping Dimensions: 17 x 16 x 5 in
-
Manufacturer Part Number (MPN): STRIKEMULTIPADXUS
- with Bag and Trigger Sticks
-
Shipping Weight: 13.5 lbs
