Audient iD14 MK2 USB Audio Interface

Featuring two Audient mic preamps from the legendary ASP8024-HE console in a compact, bus-powered format, the Audient iD14 MK2 delivers quality on the go!

Designed to take your recordings to the next level in every way, the Audient iD14 MKII 10-in/6-out audio interface delivers professional audio performance in a compact and modern desktop package, giving you everything you need to make studio quality recordings at home.

Audient Console Mic Preamps
Every iD interface features the Audient Console Mic Preamp, the same discrete circuit design found in our renowned recording console the ASP8024-HE. Designed to deliver ultra- low noise and low distortion with a touch of classic analogue warmth, iD14s two Audient mic pres will give you the professional sound you deserve.

How does it sound?
The Audient mic pre is a high grade hybrid discrete and op amp design that delivers a clean, accurate and detailed translation of your source.
With a noise floor 30,000 times quieter than the signal level your recordings will be captured with stunning clarity.

Class leading converters
iD14s converters make sure you hear every nuance, every detail of your audio, enabling you to take your recordings to the next level. Offering an incredible 126dB of dynamic range you will hear your audio more accurately, make better creative decisions and experience stunning clarity directly from your desktop.

Speaker Outputs
Connect and listen to your mixes through two sets of speakers with iD14s four line outputs. Alternatively use the extra line outputs to send audio to an external headphone amp for distribution to your artists.

Dual Headphone Outputs
Equipped with both a jack read more and mini jack connection and a powerful headphone amp capable of driving headphones up to 600Ohms, iD14 is ready to take on the most demanding recording sessions.

JFET Instrument Input
Designed to replicate the input stage of a classic valve amplifier, iD14s harmonically rich JFET Instrument Input is the perfect sonic foundation for your guitar or bass and amp sims.

Expand via ADAT
Plan for the future with iD14s digital input. Supporting both ADAT and SPDIF, iD14 gives you the option to add up to eight extra mic pre inputs letting you expand your rig and take on larger sessions.

Software Mixer
Keep it simple with the powerful but intuitive iD Mixer. Create and customise low latency headphone mixes, utilise the flexible monitor control or simply keep an eye on your levels all from one easy to use app.

Talkback
iD14s dedicated talkback technology enables you to use any audio source connected to your computer such as a built in or USB microphone as your talkback mic, freeing up valuable mic pres for recording.

Advanced Monitor Control
Speed up your workflow with the iD button. Assign any of iD14s advanced monitoring features to the iD button, including DIM, CUT, Polarity Reverse, Mono Sum, Talkback or Cue Mix monitoring, and experience complete control at your fingertips.

Create records
With Audient you will be in good company as our mic pres have been used to record 1000s of hit records all over the world.

True Phantom Power
Designed to deliver true phantom power over USB, iD14 will make sure your mics get the power they need to ensure optimal sonic performance.

USB Bus Powered
No need to find a power outlet as iD14 is powered directly from your computer via USB, without compromising on sound quality or performance.

Audio Loop-back
Audio Loop-back enables you to capture playback from applications on your computer at the same time as your microphones. Ideal for content creators, podcasters and streamers.


What is audio loopback, and how would you use it in your studio? Check out Audient's video to see how it works:


Flexible routing control
iD14s software mixer enables you to select the Loop-back source from 6 different options to suit a variety of loop-back scenarios. Endless possibilities, speedy workflow.

Features:

- 2 x Audient Console Mic Preamps
- Class Leading Converters
- 1 x JFET Instrument Input
- 4 x Line Outputs
- Dual Headphone Outputs
- ADAT Input for Expandability
- Ultra Low Latency Software Mixer
- Advanced Monitor Control
- Scrollcontrol
- Audio Loop-back
- True Phantom Power over USB
- USB3.0 Bus Powered
- All Metal Design
- Free Software + Plug-ins
read less

D.I / Instrument Input:
- RANGE: 40dB
- LINEUP: 12dBu = 0dBFS
- THD+N @ 0dBu: 0.1%
- SNR: 100dBu A-Weighted
- FREQUENCY RESPONSE MIN GAIN: 0.5dB 10Hz to 20kHz
- 1/4 TS JACK: Tip (Hot) & Sleeve (Shield)

Microphone preamplifier:
- GAIN RANGE: 58dB
- LINEUP: 12dBu = 0dBFS
- MIC MAX INPUT LEVEL: 12dBu
- MAX INPUT LEVEL: 21dBu
- INPUT IMPEDANCE (Mic): 2.8k
- INPUT IMPEDANCE (Line): >8k
- THD+N @ 0dBu: 0.00170%
- SNR: 101dBu A-Weighted
- EIN: 129dB A-Weighted
- CMRR @ 1k: >75dB
- CROSSTALK: >-100dB
- FREQUENCY RESPONSE MIN GAIN: 0.5dB 10Hz to 40kHz
- XLR COMBI FEMALE: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
- 1/4 TRS JACK: Tip (Hot), Ring (Cold) & Sleeve (Shield)

Analogue to Digital Converter:
- THD+N @ -1dBFS: 0.001%
- DYNAMIC RANGE: 120dB A-Weighted
- CMRR: >80dB
- FREQUENCY RESPONSE: 0.5dB 10Hz to 40kHz

Line Outputs (DAC):
- LINEUP: 12dBu = 0dBFS
- THD+N @ -1dBFS: 0.0006%
- DYNAMIC RANGE: 125.5dB A-Weighted
- CROSSTALK: >120dB
- FREQUENCY RESPONSE: 0.1dB 10Hz to 40kHz
- 1/4 TRS JACK: Tip (Hot), Ring (Cold) & Sleeve (Shield)

Headphone Outputs:
- LINEUP: 18dBu = 0dBFS
- THD+N @ -1dBFS: 0.0009%
- DYNAMIC RANGE: 125.5dB A-Weighted
- CROSSTALK: >116dB
- FREQUENCY RESPONSE: 0.1dB 10Hz to 40kHz
- MAXIMUM LEVEL @ 30R: 2.59V Peak, 1.827V RMS, 223mW
- MAXIMUM LEVEL @ 62R: 4.18V Peak, 2.95V RMS, 280mW
- MAXIMUM LEVEL @ 600R: 7.72V Peak, 5.46V RMS, 100mW
- 1/4 TRS JACK: Tip (Left), Ring (Right) & Sleeve (Shield)

USB-C High Speed:
- BUS POWER:
- MIN REQUIREMENT: 0.9A @ 5V >=USB 3.0 Port
- MAX REQUIREMENT: 1.5A @ 5V USB-C: Provides higher headphone outputs levels
- No. of INPUT CHANNELS: 10
- No. of OUTPUT CHANNELS: 16
- DSP MIXER LATENCY ROUND TRIP (in-to-out):
- 44.1kHz 0.65mS
- 48.0kHz 0.6mS
- 88.2kHz 0.33mS
- 96.0kHz 0.31mS
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 2.2 lbs
Shipping Dimensions: 9 x 6 x 4 in
Manufacturer Part Number (MPN): ADI ID14MK2
Blemished
Shipping Weight: 2.2 lbs
Shipping Dimensions: 9 x 6 x 4 in
Manufacturer Part Number (MPN): MBP ADIID14MK2
Warehouse Resealed
Shipping Weight: 2.2 lbs
Shipping Dimensions: 9 x 6 x 4 in
Manufacturer Part Number (MPN): NFS ADIID14MK2
