Allen and Heath Zed-6 Compact Mixer, 6-Channel

Get pro sound in a compact mixer. The A&H Zed-6 packs 2 GSPre mic preamps, and 2 high-impedance 1/4" inputs for plugging in direct guitars without DI boxes.

Allen and Heath's ZED-6 features an exceptional preamp design, created by analogue guru, Mike Griffin and developed from his highly acclaimed GS-R24 studio recording console. Known as GSPre, the preamps deliver exceptionally low noise and massive headroom, and the warmth and depth that Allen & Heaths analogue range is famous for. For tonal shaping, the precise MusiQ EQ controls have been carefully calibrated for responsiveness and precision, making it easy to shape and enhance each musical source.

Watch Hart Sawyer recording vocals, keyboard, acoustic and electric guitars directly into her A&H ZED series mixer:

Road Tough

All ZED mixers are designed and built to Allen & Heaths legendary touring grade standards to ensure a long life in the toughest environments. All channels are on individual, vertical circuit boards and all rotary controls are secured to the front panel with a steel nut to guard against impact damage.

Made for Guitars

ZED-6 comes with two Guitar DI high impedance jack inputs, allowing guitars to be plugged straight into the mixer without the need for DI boxes. Thats one less piece of gear to buy, carry and set up.


- 2 Mic / Line Inputs with separate XLR and TRS jack sockets
- 2 Stereo Inputs with TRS jack sockets
- 2 Guitar DI high impedance inputs, eliminating the need for DI boxes
- Lo-cut filter for cleaning up unwanted low frequency noise
- 2 band EQ for easy creative and corrective tonal shaping
- 60mm smooth travel fader on main mix read more
- XLR main outputs
- Flexible signal monitoring
- 8 LED signal metering
- 48V Phantom Power for condenser mics
- Robust internal power supply
WARNING: Cancer and Reproductive Harm -
read less

- Type: Analog
- Channels: 6
- Inputs - Mic: Preamps 2 x XLR
- Inputs Line: 2 x TRS (CH 1- 2), 4 x TRS (CH 3-4 ST)
- Outputs - Main: 2 x XLR (Main)
- Headphones: 1 x 1/4"
- Phantom Power: 2
- EQ Bands: 2-band, (CH 1-2) 2-band (CH 3-4 ST)
- Busses/Groups: Stereo Bus
- Rack-mountable: No
- Dimensions: (H x W x D) 3.5 x 9.8 x 9.3"
- Weight: 2.8 lbs.
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 4.75 lbs
Shipping Dimensions: 15 x 12 x 6 in
Manufacturer Part Number (MPN): ZED-6
