Vestax PMC05PRO2 2-Channel Hip Hop/Scratch Mixer

The successor of the world standard professional battle mixer!
The PMC-05PRO has been used by the majority of the world's professional battle an Hip Hop DJs for many years. Its photo coupler cross fader system with curve control, double panel system and all other features made it to be the only and the best professional battle mixer. The PMC-05PRO 2 takes over all of the features and quality of the PMC-05PRO, adding the cross fader reverse switch for more updated performance.

The crossfader is an amazing super high quality fader for smooth cutting and scratching operation. The crossfader incorporates Vestax's photo-coupler fader system, which allows control over the fader curve. From long running mixing, short cut mixing, or fast scratching mixing, the CD curve can be adjusted easily during play or pre set for any style of technique. The two Mic and PGMs each come equipped with a 2-band EQ, high/low +/-12dB and balance. The level of each PGM can be set or adjusted by using the Trim dial on each PGM. The A & B positions of the crossfader are typically set to PGM 1 and 2 respectively. But on the ProII, the CD can be reversed quickly and easily at the flick of a switch.

Features:
A cross fader reverse switch is newly provided to enable quick crab scratch technique.

A "Selectable Position" input transformer switch is also fitted, which can be fitted EIGHT positions to suit any style or preference of the DJ.

PMC-05PROII has a total of 6 inputs. (2 phono, 2 line, 2 Mic). The inputs are equipped with a 2-band equalizer. (Hi & Lo +/- 12dB) and L-R balance control.

A superior grade crossfader is fitted to PMC-05PROII enabling super smooth operation together with long life. Another first from Vestax is

Photo Coupler operation of the crossfader. This allows crossfader Curve adjustment. Now different styles of mixing, from long running mixes,to scratching and cutting can all be catered for by simple adjustment to the crossfader, even whilst "in the mix".

PMC-05PROII lives up to it's name by utilizing the same method of construction as the most expensive studio mixers. Vertical PCB's behind the faders allow the most stringent of design criteria to be met.

Technical Info

Phono inputs: Stereo (RIAA -42dBv; RCA) x 2

Line inputs: Stereo (-10dBv; RCA) x 2

Microphone, inputs: -54dBv; 1/4 in. Jack x 2

Line out: Stereo (-7dBm; RCA) x 2

Monitor head phone out: Stereo (58mW; Jack 1/4 in.)

2/4 Channels; (2 stereo, 2 mono)

Input switch (multi position transformer switch) phono/line

Input trim

2-band equalizer low + /- 12dB, high +/- 12dB

Bal. L-R

Signal input level LED bar display

Input fader (User replaceable)

3-position curve selector switch

Channel 3 + 4 (Microphone)

Volume control (each)

2-band equalizer low +/- 12dB, high +/- 12dB

Master: Output level control

Monitor: Monitor level fader, Monitor selector fader: Ch1-Ch2

Cross-fader: Channel 1-2; Cross-fader curve adjustment, Cross-fader reverse switch

Frequency Response: 25-25000 Hz +/-3dB

S/N Ratio: >75 dB THD: < 0.01%

Dimension (W x H x D): 262 x 103 x 320 mm

Weight: 3.6Kg

Power Supply: Vestax CD-15A
