World's First: Key Adjust
The DP-DJ151 allows your vinyl records to maintain a constant key (vocal) even when the platter rotation speed is changed by the Pitch slider. This is also known as "time stretching" to keep the vocals from sounding too fast or slow. This world's first feature is accomplished through the use of advanced built-in DSP processors. Key Adjust feature is available through the line output/digital output mode found only on this model.
World's First: Coaxial Digital Output
The DP-DJ151 allows you to record directly to CD-R, MiniDisc or a hard disk device through its exclusive coaxial digital output. The digi-out maintains a constant 16-bit/44.1 kHz signal, regardless of the rotational speed setting. This provides a quick and easy way to archive your vinyl digitally or to capture "samples" for studio remixing.
*Only available on this model.
Dual Output Selectable: Direct Line Level or Phono
With the built-in RIAA Phono Equalizer, the DP-DJ151 allows for direct connection to any device that requires a "line level" RCA stereo input, such as a cassette deck, A/V receiver, DJ mixer, sampler, or any other audio device that does not have a built-in "phono" input. The "Phono" out mode is for conventional hook-up to a standard DJ mixer or home receiver with "phono-in" jacks. The Selector switch is located on the rear panel for easy access.
*Only available on this model.
High Start-up Torque
Our direct drive motor with single-body construction delivers a high start-up torque of 2.2 kg/cm, enabling the turntable to quickly reach stable rotation speed in about one-quarter turn.
Selectable Stop & Start Speeds
Both the DP-DJ151 and DP-DJ101 feature advanced electronics, which allows you to change the start/stop drag speeds by a dedicated button called "BRAKE." On the DP-DJ151, 3 types of "Brake speeds" are selectable, from "Normal," "Slow," to a "smooth coast" stop. With the DP-DJ101 the platter can be stopped normally or slow. Start up speeds are also selectable from slow-drag or instant start.
Back-Lit Buttons
Back-lit buttons are provided for easy operation in dark environments (pitch On/Off, 33/45 rpm, Brake and Key Adjust On/Off).
Detachable AC Power Cord and RCA Cables
Detachable AC power cord and RCA cables for easy maintenance.
Continuous Pitch Control Maintains High-Accuracy
Pitch (rotation speed) can be consistently altered in a range of ±12%, maintaining extremely high accuracy.
Tonearm Height-adjustment
Height-adjustable and lockable tonearm with fine-adjustment of up to +6 mm has been provided to minimize vertical tracking errors.
Features
Quartz, Direct Drive Turntable
High start up torque; 2.2Kgfcm
Digital Output for direct digital connection to our new Digital/Analog DJ mixer, DN-X800
Digital Output for direct CDR, DAT, MD, PC recording
Key Adjust maintains the Key as the pitch is changed
S-shaped Tone Arm
Spare cartridge holder
Removable RCA's and power cord
Anti-Skate and Height adjustments
Fine adjust long stroke slide lever
Dust cover
Adjustable feet
Power switch guard
3 platter speeds; 33.3, 45, and 78 RPM
Pitch range of ±12%
Switchable line level or Phono output
3-way electronic brake effect; normal/medium/slow
Pop-up Target Light
No ground wire - designed to work without it
Dual voltage; 115v & 220v
Weight: 26 lbs., approximately
Technical Info
Type: Analog Turntable
Drive system: Direct drive servo control system
Speed control system: Quartz locked at ±0% pitch
Speed: 33-1/3, 45, 78 rpm
Pitch range: ±12%
Motor torque: 2.2 kg/cm
Wow & flutter: Less than 0.2 % wrms
Tonearm: Static balance type, S-shaped arm tube
Effective length: 234 mm, 9.2 in.
Overhang: 15 mm, 0.6 in.
Acceptable weight of cartridge: 3 - 10 g
Power consumption: 15 W
Dimensions (W x H x D): 448 x 156 x 350mm (17.6 x 6.1 x 13.8 in.), including dust cover
Weight: 11.8 kg (26.0 lbs.)
Note: Design and specifications are subject to change without notice.
