Xvive U5T2 Dual-Channel Digital Wireless Lavalier Camera Microphone System

Frequencies: 2400-2483.5 MHz
Wireless Range: Up to 100ft; depends on RF signal absorption, reflection and interference
Dynamic Range: MIC: 99dB; LINE: 107dB
Signal-To-Noise Ratio: MIC: 95dB; LINE: 107dB
Battery Life: 5 Hours (Xvive U5B battery)
RF Sensitivity: -86dBm
Total Harmonic Distortion: 0.2%
RF Output Power: 10 mW E.I.R.P. max
Operating Temperature Range: -18° to 57° (battery characteristics may limit this range)
Channel Count: Up to 6
Latency: 6ms
- High-Resolution Audio: 24-bit/48kHz
Transmitter Specifications
Dimensions: 51 x 34 x 65mm
Weight: 55.2g without battery
Transmitter Type: Beltpack
Housing: Molded plastic and cast metal
Charging Voltage & Current: 5V 2A
Impedance: Input 4.7kO (1KHz)
Audio Input Connector: 3.5 mm mono TRS jack
Frequency: Broad 20Hz-20KHz frequency response; Mic mode with 100Hz high-pass filter
Rms: Input max RMS (Gain=0dB) = Mic: 460mV RMS; Line: 2V RMS
Phantom Power: Mic mode: 5V; Line mode:none
Battery: Xvive U5B battery: 3.7V Rechargeable Li-ion, 860mAh (Included, Replaceable)
Battery Life: Up to 5 Hours
Antenna Impedance: 50O
Antenna Type: 1/4 wave sleeve dipole, non-removable
Number Of Antennas: 1
Display: OLED
Input Gain Control Range: Mic: -6 to +12dB; Line: 0 to +12dB
RF Output Level: 10 mW
Audio Output Max Level: Mic input: -20dBV; Line input: +6dBV
Reciever Specifications
Receiver Type: Beltpack
Dimensions: 54 x 44 x 65mm
Weight: 53g without battery
Housing: Molded plastic and cast metal
Charging Voltage & Current: 5V 2A
Battery: Xvive U5B battery: 3.7V rechargeable Li-ion, 860mAh (Included, Replaceable)
Impedance: Output 470O (1KHz)
Output Connector: 3.5 mm stereo TRS jack
Max Output Level: 2V RMS
Battery Life: Up To 5 Hours
Antenna Impedance: 50O
Antenna Type: 1/4 Wave Sleeve Dipole, Non-Removable
Number Of Antennas: 4
Display: OLED
Audio Output Max Level: 0 Dbv
Frequency Response: 20 Hz To 20 Khz
Output Gain Control Range: -54db to +24dB
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 2.2 lbs
Shipping Dimensions: 8 x 6 x 3 in
Manufacturer Part Number (MPN): U5T2
