Warm Audio WA-WL Warm Lifter Inline Active Microphone Preamplifier





zZounds Gear Experts Say...
Get more out of your low-output microphones! The Warm Lifter gives you +26 dB of gain, plus switchable 100 Hz high-pass and 3 kHz high-shelf boost filters.
Overview
The Warm Audio Warm Lifter is an inline active microphone preamp designed for low output dynamic and ribbon mics with premium features for live & studio use. Warm Lifter boasts 26dB of analog gain with true impedance matching, so any low output mic you plug in will be professionally powered for connecting to audio interfaces or mixers. Beyond gain, Warm Lifter also has a 100Hz high-pass filter and a 3kHz high-shelf boost to sculpt tones. Warm Lifter is built with premium components and rugged material. Warm Lifters are 100% tested and inspected by trained technicians with a passion for making music in Austin, TX.
- Ultra Low Noise JFET Input
- Balanced (In/Out) Signal Path
- 26 dB Of True Analog Gain
- Selectable 100 Hz (12 dB) High-Pass Filter | Selectable 3 kHz (2.5 dB) High-Shelf Boost
- 48v Phantom Powered With 4.7mA Current Draw
read less
Low-Output Mic Magic
The Warm Lifter offers 26 dB of clean gain to low-output microphones, including passive ribbons and certain dynamic models, ensuring optimal performance in both recording and live scenarios where additional gain is crucial for accurate detail and frequency response, especially when connected directly to interfaces.True 26dB of Clean Gain
Warm Lifter will always deliver 26dB of clean output gain, regardless of the mic that you choose. Unlike some inline preamps, signal boosters, and lifters, the circuit design of the Warm Lifter protects your recording from signal loss or phase issues by ensuring there is no "mismatching" of impedance between your mic of choice and the Warm Lifter.Added Frequency Flexibility
The Warm Lifter has a selectable 100 Hz high-pass filter to remove unruly low end frequencies for added clarity… read more and detail. Additionally, the Warm Lifter has a selectable 3 kHz high-shelf boost to emphasize the upper-mids and highs for clarity and detail boosted on darker mics.Impedance Matching
The Warm Lifter input impedance is 2.4k Ohm, and will consistently act as a matchmaker between low output microphones and interfaces/mixers to solve common impedance mismatch problems like signal loss, altered frequency response, and phase issues.Studio Sound & Road-Ready
The Warm Lifter houses an ultra low-noise JFET input with a fully balanced (ins/outs) signal path and operates on 48v phantom power. The incredibly durable build quality adds to the total package to deliver a critical piece of audio utility gear that you will want by your side at all times.Hand-Tested In Austin, TX
Like all Warm Audio gear, every single Warm Lifter is meticulously hand-tested and inspected by trained technicians with a passion for making music in Austin, TX USA.Features:
- Inline Active Microphone Preamp- Ultra Low Noise JFET Input
- Balanced (In/Out) Signal Path
- 26 dB Of True Analog Gain
- Selectable 100 Hz (12 dB) High-Pass Filter | Selectable 3 kHz (2.5 dB) High-Shelf Boost
- 48v Phantom Powered With 4.7mA Current Draw
Specs
- Input Impedance: 2.4k Ohm | Output Impedance: 150 Ohm
- Max-Input: -11 dBu (218mV rms) | Max-Output: 15 dBu (4.36V rms)
- THD+N @ 15dBu: -100dB (0.001%)
- Output Noise: 7.75 uV (A-weighted) with 150 Ohm Input
- Frequency Response: 10-100kHz +/-0.2 dB
- Max-Input: -11 dBu (218mV rms) | Max-Output: 15 dBu (4.36V rms)
- THD+N @ 15dBu: -100dB (0.001%)
- Output Noise: 7.75 uV (A-weighted) with 150 Ohm Input
- Frequency Response: 10-100kHz +/-0.2 dB
- Dimensions and Weight in Packaging
- Base Item
- Shipping Weight: 0.96 lbs
- Shipping Dimensions: 5 x 4 x 3 in
- Manufacturer Part Number (MPN): WA-WL
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Web: https://warmaudio.com/contact-support/
Web: https://warmaudio.com/contact-support/
