TC Electronic BH500 Bass Amplifier Head (500 Watts)
No longer available at zZounds


zZounds Gear Experts Say...
Unique features like TubeTone, SpectraComp and integrated tuning technology give this head extensive tone-shaping tool and incredible tone.
Overview
The TC Electronic BH500 feature set leaves little to be desired with its razor-sharp, tone-shaping tools such as TubeTone, SpectraComp and bass tuned tone controls. Also, the 3 user memories let you change tone at any given time while the integrated tuner allows you to tune up silently before you rock.
Check out how the string sensitive SpectraComp works:
The tweeter control is usually located on the rear side of the cabinet, but on the BH500 you can simply adjust the tweeter level right from the front panel. Further, the sound also gets modified slightly with filters giving you a much more intelligent control over the high frequencies that are critical for giving your sound that razor-sharp edge.
SpectraComp
A conventional compressor is often dominated by the lower string, but with SpectraComp, which is taken directly from the original RH450, you get 'per string' multi-band compression that evens out the compression across all strings. In short, you get an even and rock solid tone that cuts through any mix whether you play fingerstyle, with a heavy pick or slap the strings hard.Check out how the string sensitive SpectraComp works:
TubeTone
The TubeTone effect was originally introduced on RH450. Most transistor designs try to replicate tube sound using one small preamp tube, but why not take the crucial characteristics of a full preamp and power amp into account? Both are essential to the sound when you want that classic tube warmth as well as when you go for a full-on overdriven rock sound with a massive punch.Presets
BH500 can store three of your favorite tones. For instance, if you need a nice chunk of overdrive on specific passages, presets are king. Not to mention, with great sounding bass tones and seamless switching between them, you will be able to focus on the important thing - rocking out!Built-in bass tuner
Every once in a while, you need… read more to tune up, and whenever that happens, just let the built-in tuner guide you. It's simple, it lets you tune silently, and it gets you back to rocking in no time.Tone Controls and TweeterTone
EQ is always a bass essential, so they have equipped BH500 with a great sounding, 4-band EQ which is perfect for shaping your fundamental tone. Further, with two contour filters you can scoop the mid-frequencies, which creates an amazing low-end punch on demand.The tweeter control is usually located on the rear side of the cabinet, but on the BH500 you can simply adjust the tweeter level right from the front panel. Further, the sound also gets modified slightly with filters giving you a much more intelligent control over the high frequencies that are critical for giving your sound that razor-sharp edge.
Connections
Just plug and play. And for rehearsing or jamming along you can connect your portable music player to the AUX input. If you don't want to disturb the neighbors, plug in your headphones and the drivers will be muted automatically. Finally, you can send a signal to a sound-engineer via the balanced XLR output - or to an audio interface when you are recording the rock hits of tomorrow. read lessSpecs
Input Section
Input connector: 1/4 jackInput impedance: 1 MOhm / 100 pF
Gain range: -96 to 36dB
Tone Control
Bass: Center Freq: 100Hz (Gain: +15/-24dB)Low Mid: Center Freq: 335Hz (Gain: +15/-24dB)
High Mid: Center Freq: 900Hz (Gain: +15/-24dB)
Treble: Center Freq: 1600Hz @ Gain: -24 to 0dB; 4000Hz @ Gain 0 to +15dB
Tweeter Tone: 0 to 10, L-PAD Cabinet Recreation
Tube Tone: 0 to 10, Tube amp Recreation
Spectra Comp: 3 band Spectral Compression
User Memories: 3 memory locations storing all front panel controls except Mute & Master Level
Tuner: Bass Tuner, "On" when muted
Tuning range: B0 (30.87Hz) to G4 (392.00Hz)
Mute: Mutes speaker out, Phones out and Balanced out
Master Level / Headphones Output: Studio quality headphone amp
HP Out Impedance: 40 to 600 Ohm
Mains supply: 100 - 120V~ or 220 - 240V~ 50/60Hz (65W @ 1/8 of Max. Output)
Power rating: 500w (1000w Peak)
Speaker output: Neutrik Speakon
Balanced output: Balanced XLR, Pre/Post Pre-amp
Bal. Out Max.: +2dBu
Bal. Out Optimal Load Impedance: 600 Ohm
Rehearsal input: RCA, Left/Right input, fits to iPod (R)
Dimensions: 462 x 135 x 380 mm / 18.7 x 5.4 x 15.0"
Weight: 13 kg / 29 pounds
Finish: Tolex covered. Handcrafted wooden box
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Web: https://www.tcelectronic.com/service.html
Web: https://www.tcelectronic.com/service.html
Reviews
Reviewers gave this product an overall rating of 5 out of 5 stars.
(12 ratings)
Submitted November 3, 2013 by Gregory Williams in San Diego, CA
"TC BH500"
Verified Purchaser
zZounds has verified that this reviewer purchased this specific product from us.
Fantastic, Incredible, Superb, Powerful, can not go wrong with this bass head. I have this matched to a GK 410 Neo Cabinet. The two together make sound like a pro. I am a above average bassist. Many tone variations are able to be achieve. Have not use the tone print feature. I have not had the need to use it yet. Know that it is available, is good enough for me. For sure, you will not be lacking power. This is a great buy. Turner is touchy, but accurate. Just have to get use to it. Easy to use, not complicated. Not being a smart azz, but if you have a junior high level IQ, you will be able to operate this bass head, and be very pleased with the results.
Musical Background:
Have been playing seriously for the past decade, but, overall since the late 80's. Use to play in bands, headache! I play at hom
Musical Style:
All music except country. I prefer play jazz, funk, blues. I enjoy exploring my own creativity of music. Combining jazz and funk
2 of 2 people (100%) people found this review helpful. Did you?
