The Tascam SX-1LE Plus is the only integrated digital workstation that's packed with professional features! Compared with the competition and it's clear which workstation has the feature set you need to get serious projects done. Like 100mm touch-sensitive moving faders, full (not just snapshot) automation and simultaneous 16-track hard disk recording at 24-bits (not yesterday's 16-bit resolution). Add 16 mic/line inputs, 40-channel mix engine, 6-channel stem recorder, 128-channel MIDI sequencer and external XVGA output and you have a potent productivity tool.
Easy to set up and use
Each component of the SX-1LE Plus was carefully designed to offer world-class operation on its own. But with its intuitive design and natural user experience, the SX-1LE is much more than the sum of its parts. Its user interface was designed to function as a seamlessly integrated unit. Audio professionals and songwriters alike will feel comfortable relying on the SX-1LE for their most important projects.
The recording section is designed so that you can begin recording music after only four button presses. Its 16-track, 24-bit hard disk recorder is based on our best-selling MX-2424 recorders for world-class sound quality and reliability. Virtual tracks, up to 999, mean that you don't need to record over a take to try it again. The LCD display and VGA monitor output make it simple to see what you've recorded and, along with the included mouse and keyboard, provide an editing interface to rival high-end digital workstations.
mixing and generous, expandable I/O
A powerful 40-input digital mixing console is integrated with the SX-1LE Plus' recording section for seamless operation and stunning audio quality. Each of the 32 channel inputs has powerful processing features like 3-band parametric EQ and dynamics, and can be routed to the 8 buss outputs or stereo outs. Four stereo effects returns are provided for the four realtime DSP plug-ins.
The SX-1LE has all the inputs and outputs you need for large recording sessions:
ADAT Optical Digital 8-channel Input
ADAT Optical Digital 8-channel Output
BNC Video Clock In and Out/Thru
BNC Word Clock In and Out/Thru
RS-422 Machine control
1/4 in. TRS SMPTE Timecode Input
MIDI Timecode Input
(4) MIDI Outputs
XVGA Monitor Output
10/100 base T Ethernet connection
Three IF/DM format expansion slots for Analog, TDIF, ADAT or AES/EBU 8-channel expansion
(2) 1/4 in. Stereo Headphone Jacks
(16) Mic Inputs with Neutrik XLR connectors
Switchable Phantom Power
(16) 1/4 in. TRS Balanced Line Inputs
RCA 2-track Stereo Line Input
(16) 1/4 in. TRS Insert Jacks
Stereo XLR Line Outputs
Stereo RCA Line Outputs
(4) 1/4 in. TRS Balanced Aux Outputs
Stereo 1/4 in. TRS Balanced Large Monitor Outputs
Stereo 1/4 in. TRS Balanced Small Monitor Outputs
Stereo 1/4 in. TRS Balanced Studio Monitor Outputs
(2) S/PDIF Digital Inputs
(2) S/PDIF Digital Outputs
Sophisticated MIDI sequencing
The 128-track MIDI sequencer adds even more recording capability. With four MIDI outputs, your arrangements have access to 64 MIDI channels. You get step and continuous recording modes, non-destructive quantize/diatonic transposition, MIDI reverse play, event list editing and graphic (piano roll) editing. The SX-1LE Plus' SMPTE, MIDI and RS-422 features allow synchronization with sequencers, DAWs or video playback.
Quick and easy recording interface
With just four button presses you can begin recording - perfect for those moments when you just need to get a new idea down. As your arrangement begins to take shape, you'll appreciate the 16 tracks of 24-bit recording and the clarity of the 16 phantom-powered mic pres. The VGA display output allows you to edit your tracks until you've assembled the perfect take.
When you're ready to mix, you get 3-band EQ on each of the 32 input channels, plus 4 stereo effects returns for the built-in or external effects -- including TC Works reverb and Antares mic modeling effects. All of your mixing moves are fully automated using the touch-sensitive moving faders, and automation can be edited on the display to get it just right.
Full 5.1 surround mix and monitoring capabilities
With its dedicated 6-channel stem controller and recorder, the SX-1LE Plus is a good fit for studios looking to capture and manipulate surround audio. The SX-1LE Plus implements an intuitive interface for working in surround. Using the comprehensive GUI, you can place your audio anywhere within a 360-degree field to set the levels and panning for your surround playback. Also included are advanced surround controls for setting divergence and LFE, as well as the ability to cancel the center channel.
There's also a wide variety of monitoring functions with the SX-1LE Plus. An onboard speaker switcher allows access to its three speaker outputs. Nearfield and soffit speaker control room outputs can be fed by a large number of sources, including left/right, auxes 1-6, cue mix, 2-track inputs and others. Two headphone outputs are also included, fed by the control room or studio output signals.
No B-Room should B without one
One of the limiting factors in choosing gear for projects rooms is space, since fitting a large console, multitrack recorder, outboard signal processing, DAW-style editing, mixdown tools and MIDI sequencing can take up more room than a 10 x 10 area can provide. But the SX-1LE Plus offers all of these abilities and more, in a compact package that's slightly over 3 feet wide by 2 feet deep.
For multimedia projects, the SX-1LE can be synchronized using MIDI or SMPTE timecode, or using RS-422 (Sony 9-pin). There's also video and word clock inputs and outputs for digital audio routing, in addition to two sets of S/PDIF digital inputs and outputs and ADAT optical digital I/O. As your studio expands, you can add another 24 digital or analog inputs and outputs using the three expansion slots.
Each of the SX-1LE Plus' components offer the feature set and audio quality expected for high-end music and audio production, making it an attractive choice for smaller yet commercially viable recording environments.
The all-in-one church live sound and production solution
The SX-1LE Plus is the perfect all-in-one solution for front-of-house audio mixing, recording ceremonies and productions, creation of Compact Discs for distribution, and content creation for classes and special promotions.
It offers the ability to create sophisticated live mixes and perform mixdowns with EQ and effects - all with the professional quality that today's congregations expect. Professional features like MIDI sequencing, DAW-style editing and touch-sensitive moving fader automation ensure that your productions will sound polished and dynamic.
40-input, 32 x 8 digital mixer with 100mm touch-sensitive faders and dynamic automation of all parameters
48kHz, 24-bit, 16-channel hard disk recorder with built-in IDE drive
16 premium mic preamps with phantom power
Built-in CD-RW drive for creating Red Book audio CDs, data backup & archiving, and importing sounds from audio or data CDs
Highly integrated and intuitive waveform, MIDI, and automation data editing via an internal recording/editing engine
Onboard LCD screen displays editing and automation information including waveforms
XVGA output to optional monitor
Jog/shuttle wheel for scrubbing audio and MIDI data simultaneously
Complete surround mixing capabilities with the ability to record a full 5.1 mix to the internal HD in addition to the original 16 audio tracks
Small footprint: Takes up just over 3 feet of studio space
100 BaseT Ethernet port
128-track MIDI sequencer with advanced editing modes available on the fly, with standard and step record modes and highly accurate timing derived from the internal sample clock. Each of the 64 MIDI outputs can be mapped to channel strips on the console
Extensive analog, digital, MIDI and computer interfacing: 16 balanced XLR inputs, 16 1/4 in. TRS line inputs, TRS inserts on each analog input, an onboard speaker switcher, eight channels of ADAT Optical digital interface, two stereo S/PDIF inputs (with sample rate conversion) and outputs, two MIDI inputs (for MIDI controllers and MIDI Time Code), four MIDI outputs, separate studio and control room monitoring and more
MTC synchronization and LTC chase
Built-in effects by TC Works and Antares
Expansion slots for 24 more channels of digital I/O (including optional multichannel interfaces for AES/EBU, TDIF, ADAT Optical) or additional analog I/O
Compatible with the complete line of SX-1 I/O cards
