Samson Stage 5H VHF Handheld Wireless System

No longer available at zZounds
Samson HT5 Transmitter
Frequency Range: 173.80 MHz to 213.20 MHz, 25 frequencies

OSC System: Crystal controlled, x12 multiplication

RF Power: 20 mW

Operating Range: 300 ft

Frequency Stability: +/- 10 ppm

Antenna Type: Internal

Audio Frequency Response: 40 Hz to 15 kHz +/- 3 dB

Pre-Emphasis: 50 Microseconds

Noise Reduction System: NE571 based compandor

Signal To Noise Ratio: > 100 dB

T.H.D.: < 1% @ 1 kHz

Current Consumption: 34 mA (typical)

Battery Life: 6 hours (typical)

Operating Temperature: -10 to +55 degrees C

Controls:
- Power On/Off
- Audio On/Off
- Level Control (Trimpot)

LED Indicator: Battery (high/medium/low)

Dimensions (WxH): 1.46 x 9.17 inches (37 x 233 mm)

Weight: 7.1 oz (200 g)

Samson SR5 Receiver
Frequency Range: 173.80 MHz to 213.20 MHz, 25 frequencies

Receiving Mode: 80KF3E

Sensitivity: < 3 microvolts for 20 dB SINAD (< 10 microvolts for 50 dB S/N

Selectivity: 120 kHz BW, nominal @ -6 dB, +/- 300 kHz (adj CH), -75 dB

Squelch Sensitivity: 3 microvolts to 250 microvolts adjustable

Intermediate Frequency: 10.7 MHz

Local Oscillator System: Crystal controlled

Noise Reduction System: NE571 based compandor

De-emphasis: 50 microseconds

Signal To Noise Ratio:
- > 100 dB (IHF-A) line out
- > 90 dB (IHF-A), mic out

Audio Frequency Response: 40 Hz to 15 kHz +/- 3 dB

T.H.D.: < 1% @ 1 kHz

Audio Output Levels:
-10dB unbalanced (1/4 phone connector)
-20 dBm / -40 dBm balanced (XLR connector)

Audio Output Impedance: 5 k ohms unbalanced, 600 ohms balanced

Antenna: 1/4 wavelength telescopic

Operating Temperature: -10 to +55 degrees C

Controls: Volume, Squelch, Power

LED Indicators: TX On; AF Level (6 LEDs); RF Level (6 LEDs)

Power Requirement:
- 12 Volts DC
- 100 mA typical (110 mA max)
- AC adapter supplied

Dimensions (WxHxD): 8.5 x 1.75 x 4.6 in. (216 x 44 x 116 mm)

Weight: 0.75 lb (20 g)
