zZounds Gear Experts Say...
In need of a PA upgrade? The RCF ART 735-A packs 1400 watts of 2-way peak power and is equipped with a 15" woofer for clear, defined low end.

ART 735-A MK5 is a unique product in its category. The 3.0" compression driver offers unique vocal clarity and sound projection. The 15" woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalization, phase control, soft limiting and speaker protections.

Features:

- 132 dB Max SPL
- 1400 WATT 2-way peak power
- 90* x 60*, Wide dispersion constant directivity horn
- Innovative DSP Processing
- 3.0" Titanium diaphragm Compression Driver
- 15" Woofer
- FiRPHASE Technology
- XBOOST Low Frequencies Enhancer


Take a closer look at the story behind the ART 7 MK5 series in RCF's video:

- Speaker Type: Active two-way powered loudspeaker
- Frequency Response (-10dB): 45 Hz - 20,000 Hz
- Coverage Pattern: 90° horizontal x 60° vertical
- Max SPL (Peak): 132 dB @ 1m
- LF Transducer: 15" woofer with 2.5" voice coil
- HF Transducer: 1.4" titanium compression driver with 3.0" voice coil
- Crossover Frequency: 800 Hz
- Amplifier Type: Class-D bi-amplifier with DSP
- Amplifier Power (LF): 1000W Peak
- Amplifier Power (HF): 400W Peak
- Input Connectors: XLR, Jack
- Output Connectors: XLR
- Power Supply: SMPS (Switch Mode Power Supply)
- Enclosure Material: Polypropylene composite
- Grille Material: Steel
- Mounting Options: 35mm pole mount, M10 flying points

Dimensions and Weight in Packaging

Base Item

  • Shipping Weight: 56.6 lbs
  • Shipping Dimensions: 30 x 20 x 18 in
  • Manufacturer Part Number (MPN): 13000857

For support or warranty questions, please contact the manufacturer:
Phone: 732-902-6100
Email: service@rcf.it or TechSupport@rcf.it
Web: https://www.rcf.it/en/support
