Phil Jones BG-80 Double 4 Plus Bass Combo Amplifier (90 Watts, 2x4")






zZounds Gear Experts Say...
A compact bass amp with serious tone, the Phil Jones BG80 delivers 90 watts through dual 4-inch drivers for punchy, full-range sound in a portable package.
Overview
With increased power and more features, the Double Four Plus BG-80 is a worthy successor to PJB's legendary BG-75 Double Four model. The BG-80 is a 90-watt single channel bass combo with two four-inch speakers and a 3-band EQ that is perfectly tailored for bass guitar. Other features include an auxiliary input for iPad/iPod, smartphone or drum machine, stereo headphone-out jack and a line out for recording.
Recorded music sounds great through the Bluetooth function (V5.1 with aptX HD). In addition, the Double Four Plus is equipped with a DC input (USB Type-C port) connection which supports a mobile power bank of USB PD (Power Delivery) Protocol. This provides the ultimate in "Tone To Go" and busking possibilities, even where AC power isn't available. The BG-80 is ideal for all kinds of basses, and can handle the open B string on a 5- string bass with ease.
To get the ultimate bass sound from a small speaker cabinet, PJB has applied its cutting-edge experience in designing small speakers to achieve a 4 inch driver with Swiss watch precision. Using our extensive R&D facility which includes the largest an-echoic chamber in the bass guitar amplifier industry and the transducer Klippel measurement system with laser technology, PJB was able to develop the proprietary PJB "long-thro" 4-inch speakers that have full frequency range up to the highest audio frequencies. Not only does this give greater clarity and transparency to your instrument, but also a high-fidelity sound to any backing… read more track fed into the auxiliary input.
The cabinet is small and portable and built to the same high-quality standards of all PJB cabinets. What you hear from the Double Four Plus is the closest you can get to how your instrument actually sounds, and, is remarkably loud for its size. This latest model in the Double Four series is a remarkable achievement in design, features, and tone.
read less
Recorded music sounds great through the Bluetooth function (V5.1 with aptX HD). In addition, the Double Four Plus is equipped with a DC input (USB Type-C port) connection which supports a mobile power bank of USB PD (Power Delivery) Protocol. This provides the ultimate in "Tone To Go" and busking possibilities, even where AC power isn't available. The BG-80 is ideal for all kinds of basses, and can handle the open B string on a 5- string bass with ease.
To get the ultimate bass sound from a small speaker cabinet, PJB has applied its cutting-edge experience in designing small speakers to achieve a 4 inch driver with Swiss watch precision. Using our extensive R&D facility which includes the largest an-echoic chamber in the bass guitar amplifier industry and the transducer Klippel measurement system with laser technology, PJB was able to develop the proprietary PJB "long-thro" 4-inch speakers that have full frequency range up to the highest audio frequencies. Not only does this give greater clarity and transparency to your instrument, but also a high-fidelity sound to any backing… read more track fed into the auxiliary input.
The cabinet is small and portable and built to the same high-quality standards of all PJB cabinets. What you hear from the Double Four Plus is the closest you can get to how your instrument actually sounds, and, is remarkably loud for its size. This latest model in the Double Four series is a remarkable achievement in design, features, and tone.
Specs
- Amplifier Type: Full Digital with DSP
- Power Output: 90 Watts(2x45W) 1% THD
- Signal to Noise Ratio: =85dB(A)(EQ off, Volume on Full)
- Impedance:
- Input: =270KO / 22pF
- Speaker:
- 2x 4-inch Full Range Speaker
- 1x Rectangular Auxiliary Low Frequency Radiator.
- Usable Frequency Response: 40Hz to 17KHz
- Levels:
- Hight Input: 120mV-2 V
- Low Input: 400mV-3V
- Aux Input: 200mV (MAX)
- Bluetooth Input: 300mFFS
- EQ Center Frequencies:
- Bass Shelf 100Hz, +/- 15dB
- Mid 1KHz Bandwidth 120Hz-10Kz, +/- 15dB
- Treble Shelf 10KHz, +/- 15dB
- Included Parts: 6' AC Power Cord, 5.5' Audio Cord
- Dimensions (W\0xD7H\0xD7D): 13"\0xD78" \0xD78.5"
- Net Weight: 11.5 lbs
- Power Output: 90 Watts(2x45W) 1% THD
- Signal to Noise Ratio: =85dB(A)(EQ off, Volume on Full)
- Impedance:
- Input: =270KO / 22pF
- Speaker:
- 2x 4-inch Full Range Speaker
- 1x Rectangular Auxiliary Low Frequency Radiator.
- Usable Frequency Response: 40Hz to 17KHz
- Levels:
- Hight Input: 120mV-2 V
- Low Input: 400mV-3V
- Aux Input: 200mV (MAX)
- Bluetooth Input: 300mFFS
- EQ Center Frequencies:
- Bass Shelf 100Hz, +/- 15dB
- Mid 1KHz Bandwidth 120Hz-10Kz, +/- 15dB
- Treble Shelf 10KHz, +/- 15dB
- Included Parts: 6' AC Power Cord, 5.5' Audio Cord
- Dimensions (W\0xD7H\0xD7D): 13"\0xD78" \0xD78.5"
- Net Weight: 11.5 lbs
- Dimensions and Weight in Packaging
- Black
- Shipping Weight: 13.3 lbs
- Shipping Dimensions: 14 x 11 x 10 in
- Manufacturer Part Number (MPN): Double 4 Plus BG-80B
- Red
- Shipping Weight: 13.4 lbs
- Shipping Dimensions: 14 x 11 x 11 in
- Manufacturer Part Number (MPN): Double 4 Plus BG-80R
- White
- Shipping Weight: 13.55 lbs
- Shipping Dimensions: 14 x 11 x 11 in
- Manufacturer Part Number (MPN): Double 4 Plus BG-80W
