Peavey PVXp 15 DSP 2-Way Powered Loudspeaker (830 Watts, 1x15")

Fan-cooled, with cutting-edge DSP and Peavey's Quadratic Throat Waveguide technology, the PVXp 15 DSP powered speaker squeezes the most out of every watt.
The Peavey PVXp 15 DSP 2-Way Powered Loudspeaker has up to 3 times the power of many of it competitors. This high powered speaker features DSP with more presets than ever before and a larger cabinet to increase the bass response.

The PVXp 15 DSP features a reliable bi-amped power section that provides a total of 830 Watts of peak available dynamic power. With that much available power, speaker protection is critical. Advanced digital signal compression prevents audible overload, protecting the speakers from harmful distortion at high output levels.

This powered enclosure also includes heavy duty speaker drivers; it features a 15" woofer with a 2-3/8" voice coil and a 50 oz. magnet. This is coupled with the RX14 compression driver that includes a 1.4" titanium diaphragm on a 100-degree horizontal x 50 degree vertical pattern asymmetrical horn.

The PVXp 15 DSP provides a balanced input via a combination jack that accepts a balanced TRS 1/4" input, as well as a balanced XLR input and summed RCA jacks. There are two balanced Thru outputs, a male XLR and a 1/4" TRS. The LCD display and EQ presets, along with other operating parameters are accessed via a one-knob selector.


- Two-way bi-amplified analog amp powered speaker system
- Heavy-duty woofer with a 2-3/8" voice coil & 50 oz magnet
- RX 14 compression driver, with 1.4" titanium diaphragm
- 630 watts peak read more dynamic woofer power, 200 watts peak dynamic tweeter power
- DSP processing is 64 bit double-precision
- DSP I/O is at 48 kHz and 24 bits, with low-jitter, professional grade components
- Fan cooled for maximum reliability
- Patented Quadratic Throat Waveguide technology, 100 by 50 degree coverage
- Asymmetrical horn aims the sound down at the audience, not over their heads
- Input is via a combo female XLR and 1/4" TRS phone jack with balanced input
- A Mic/Line switch provides for two different gain settings
- Thru output is via a male XLR jack and 1/4" TRS phone jack
- Multiple Factory Preset EQ settings
- Rugged plastic injection-molded trapezoidal enclosure
- Full-coverage perforated steel grille, with powder coat finish
- Pole mount molded-in for 1 3/8” diameter poles
- Top, bottom and right side flying point inserts
WARNING: Cancer and Reproductive Harm -
read less
- Dimensions (HxWxD): 28.25" x 18.9" x 18.71" / 717.6 x 480 x 475.2 mm
- Weight: 51 lbs / 23.13 kg
Dimensions and Weight in Packaging
Base Item
Shipping Weight: 59.25 lbs
Shipping Dimensions: 32 x 22 x 21 in
Manufacturer Part Number (MPN): PEV PVXP15DSP
Shipping Weight: 118.5 lbs
If you have additional warranty questions, please contact the manufacturer at 877-732-8391
