Mackie SA1521 Active 15 in., 2-Way Loudspeaker
No longer available at zZounds
zZounds Gear Experts Say...
500 Watts. Wide dispersion.
Overview
The new SA1521 truly fulfills the demand for more of everything. More power (500 watts). More transducer (RCF Precision 15 in. LF transducer). More SPL (133dB peak!).
The SA1521 is a truly collaborative effort between Mackie, EAW Engineering and RCF Precision. It's an honest-to-gosh technology breakthrough — an active, full-bandwidth solution with seamlessly integrated power and control, premium transducers and that wonderfully wide dispersion that lets everyone in the audience hear the same thing.
Put the SA1521 up against the most popular 15 in. 2-way systems in the world and what happens? You suddenly discover that the competition is obsolete — problematic in design, poor in definition and basically nothing more than a 15 in. and a 1 in. playing separate tunes.
It doesn't take long to realize that the new SA1521 truly re-defines 2-way 15 in. speaker systems. The SA1521 is an Active speaker system that expands the performance envelope of previous Mackie Active products. It has better resolution, output, and linearity than the SRM450 and higher output than the SR1530 product. It also sets a new standard for 15 in. woofer/1 in. compression driver based systems through its smoothness, power and mid-band performance. This leads to a compact product with a broad range of applications that is powerful and very easy to use.
Design Overview
Mackie's SA1521 is an active 2-way sound reinforcement speaker system designed for extreme accuracy, high output, and smooth dispersion… read more across the entire audio frequency range. It integrates 500 watts of amplifier power, active control electronics, and RCF Precision components into a speaker system with 100 dB sensitivity (1 watt @1 meter). The resulting high resolution and clarity in the critical low-mid and mid-range frequencies are unparalleled for a 15 in. loaded, 2-way speaker system.
Several state of the art advancements in transducer technology have been incorporated in the design of the SA1521. The compression driver uses a new 1.75 in. titanium diaphragm featuring a 3-slot, optimized geometry phase plug. When coupled to the low-distortion, high-output horn, the SA1521 provides uniform power response and correct phase alignment characteristics at the crossover frequency. With the resulting 75 read less
The SA1521 is a truly collaborative effort between Mackie, EAW Engineering and RCF Precision. It's an honest-to-gosh technology breakthrough — an active, full-bandwidth solution with seamlessly integrated power and control, premium transducers and that wonderfully wide dispersion that lets everyone in the audience hear the same thing.
Put the SA1521 up against the most popular 15 in. 2-way systems in the world and what happens? You suddenly discover that the competition is obsolete — problematic in design, poor in definition and basically nothing more than a 15 in. and a 1 in. playing separate tunes.
It doesn't take long to realize that the new SA1521 truly re-defines 2-way 15 in. speaker systems. The SA1521 is an Active speaker system that expands the performance envelope of previous Mackie Active products. It has better resolution, output, and linearity than the SRM450 and higher output than the SR1530 product. It also sets a new standard for 15 in. woofer/1 in. compression driver based systems through its smoothness, power and mid-band performance. This leads to a compact product with a broad range of applications that is powerful and very easy to use.
Design Overview
Mackie's SA1521 is an active 2-way sound reinforcement speaker system designed for extreme accuracy, high output, and smooth dispersion… read more across the entire audio frequency range. It integrates 500 watts of amplifier power, active control electronics, and RCF Precision components into a speaker system with 100 dB sensitivity (1 watt @1 meter). The resulting high resolution and clarity in the critical low-mid and mid-range frequencies are unparalleled for a 15 in. loaded, 2-way speaker system.
Several state of the art advancements in transducer technology have been incorporated in the design of the SA1521. The compression driver uses a new 1.75 in. titanium diaphragm featuring a 3-slot, optimized geometry phase plug. When coupled to the low-distortion, high-output horn, the SA1521 provides uniform power response and correct phase alignment characteristics at the crossover frequency. With the resulting 75 read less
Specs
-3dB response: 57Hz - 18kHz
-10dB response: 49Hz - 20kHz
Max SPL long-term: 130 dB
Max SPL Peak: 133 dB
Crossover Point: 1300Hz
Input: balanced/unbalanced Female XLR
Loop-Through (Parallel with Input): balanced/unbalanced Male XLR
Level Control: Rotating knob (-15 to +4 dB), center detent @ 0 dB
Total Amplifier Power: 500 watts Continuous*
High Frequency: 100 watts*
Type Class: AB
Rated THD: .03%
Low Frequency: 400 watts*
Type: Class G Hybrid
Rated THD: 0.03%
*Rated power is continuous RMS wattage into transducer's rated impedance @ 1kHz for the HF amplifier and @ 100Hz for the LF amplifier
**-6dB
High Frequency Section
Diaphragm Size: 1.75 in.
Horn Exit Diameter: 1.0 in.
Phase Plug: 3-Slot Optimized Geometry
Diaphragm Material: Damped titanium
Magnet Type: Ferrite
Horn Design
Horizontal Coverage**: 75 1kHz to 10kHz avg.
Vertical Coverage**: 65 1kHz to 10kHz avg.
Type: Constant Directivity
Mouth Size: 10.6 x 10.6 in. (27 x 27cm)
Throat size: 1.0 in. (2.54 cm)
Low Frequency Section
Number of Drivers: 1
Woofer Size: 15 in.
Diaphragm: Material Epoxy-reinforced Cellulose
Magnet Type: Ferrite
General
Basic Design: Trapezoidal
Material: 13-ply Baltic birch/resin end caps
Finish: Wear-resistant black PVC vinyl
Handles: 2 on sides, 1 top, 1 bottom
Grill: Perforated metal with weather-resistant coating
Line input Power: US 120 VAC, 60Hz
Recommended amperage service: 13 Amps
AC Connector: 3-pin IEC 250 VAC
Control System Function: Electronic Crossover, Phase Alignment, Time Correction, Equalization, Parametric equalization
Protection: Low Frequency Dynamic Bass Protection, RMS Limiting, Power Supply and Amplifier Thermal Protection
Display LEDs: Signal Present, Limit, Power ON, and Thermal (Cool Down Auto Reset)
Height: 32.0 in. (81.3 cm)
Width: Front 19.06 in. (48.4 cm)
Width: Back 13.9 in. (35.3 cm)
Depth: 18.11 in. (46.0 cm)
Weight: 83.6 lbs. (38 kg)
-10dB response: 49Hz - 20kHz
Max SPL long-term: 130 dB
Max SPL Peak: 133 dB
Crossover Point: 1300Hz
Input: balanced/unbalanced Female XLR
Loop-Through (Parallel with Input): balanced/unbalanced Male XLR
Level Control: Rotating knob (-15 to +4 dB), center detent @ 0 dB
Total Amplifier Power: 500 watts Continuous*
High Frequency: 100 watts*
Type Class: AB
Rated THD: .03%
Low Frequency: 400 watts*
Type: Class G Hybrid
Rated THD: 0.03%
*Rated power is continuous RMS wattage into transducer's rated impedance @ 1kHz for the HF amplifier and @ 100Hz for the LF amplifier
**-6dB
High Frequency Section
Diaphragm Size: 1.75 in.
Horn Exit Diameter: 1.0 in.
Phase Plug: 3-Slot Optimized Geometry
Diaphragm Material: Damped titanium
Magnet Type: Ferrite
Horn Design
Horizontal Coverage**: 75 1kHz to 10kHz avg.
Vertical Coverage**: 65 1kHz to 10kHz avg.
Type: Constant Directivity
Mouth Size: 10.6 x 10.6 in. (27 x 27cm)
Throat size: 1.0 in. (2.54 cm)
Low Frequency Section
Number of Drivers: 1
Woofer Size: 15 in.
Diaphragm: Material Epoxy-reinforced Cellulose
Magnet Type: Ferrite
General
Basic Design: Trapezoidal
Material: 13-ply Baltic birch/resin end caps
Finish: Wear-resistant black PVC vinyl
Handles: 2 on sides, 1 top, 1 bottom
Grill: Perforated metal with weather-resistant coating
Line input Power: US 120 VAC, 60Hz
Recommended amperage service: 13 Amps
AC Connector: 3-pin IEC 250 VAC
Control System Function: Electronic Crossover, Phase Alignment, Time Correction, Equalization, Parametric equalization
Protection: Low Frequency Dynamic Bass Protection, RMS Limiting, Power Supply and Amplifier Thermal Protection
Display LEDs: Signal Present, Limit, Power ON, and Thermal (Cool Down Auto Reset)
Height: 32.0 in. (81.3 cm)
Width: Front 19.06 in. (48.4 cm)
Width: Back 13.9 in. (35.3 cm)
Depth: 18.11 in. (46.0 cm)
Weight: 83.6 lbs. (38 kg)
Documents and Manuals
For support or warranty questions, please contact the manufacturer:
Phone: 800-898-3211
Email: support@mackie.com
Web: https://mackie.com/en/support/contact
Phone: 800-898-3211
Email: support@mackie.com
Web: https://mackie.com/en/support/contact
