Eminence GuitFiddle Speaker (100 Watts, 12")

This is a carousel with one large image and a track of thumbnails on the left side. Select any of the thumbnail buttons to change the main image. You may also use the left and right arrow keys to navigate between images.
Eminence GuitFiddle Speaker (100 Watts, 12"), 8 Ohms, Action Position Back
Eminence GuitFiddle Speaker (100 Watts, 12"), 8 Ohms, Action Position Back
Eminence GuitFiddle Speaker (100 Watts, 12"), 8 Ohms, Action Position Back
Eminence GuitFiddle Speaker (100 Watts, 12"), 8 Ohms, Action Position Back Eminence GuitFiddle Speaker (100 Watts, 12"), 8 Ohms, Action Position Back Eminence GuitFiddle Speaker (100 Watts, 12"), 8 Ohms, Action Position Back
zZounds Gear Experts Say...
Get a speaker that's made for violin -- the Eminence GuitFiddle. Its mellow high-mids reduce bow noise and impart a smooth tone to violin or electric guitar.

The Eminence 12 inch GuitFiddle speaker was created and voiced specifically for fiddle. Reduced bow friction noise and tame upper-mids. It's also great for guitar if you want thick tone with warm, smooth, more mellow mids and highs.
WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

- Nominal Basket Diameter: 12", 305 mm
- Nominal Impedance: 8 O
- Watts: 50 W
- Resonance: 82 Hz
- Usable Frequency Range: 80 Hz - 4.5 kHz
- Sensitivity*: 100.1 dB
- Magnet Weight: 38 oz.
- Gap Height: 0.31", 7.9 mm
- Voice Coil Diameter: 2", 51 mm

THIELE & SMALL PARAMETERS
- Resonant Frequency (fs): 82 Hz
- DC Resistance (Re): 7.34 O
- Coil Inductance (Le): 0.63m H
- Mechanical Q (Qms): 15.49
- Electromagnetic Q (Qes): 0.58
- Total Q (Qts): 0.56
- Compliance Equivalent Volume (Vas): 57.81 liters / 2.04 cu.ft.
- Peak Diaphragm Displacement Volume (Vd): 43.09 cc
- Mechanical Compliance of Suspension (Cms): 0.14 mm/N
- BL Product (BL): 13.11 T-M
- Diaphragm Mass Inc. Airload (MMs): 26 grams
- Efficiency Bandwidth Product (EBP): 141
- Maximum Linear Excursion (Xmax): 0.79 mm
- Surface Area of Cone (Sd): 545.4 cm2

MOUNTING INFORMATION
- Sealed: Acceptable
- Vented: Acceptable
- Driver Volume Displaced: 0.071 cu.ft. / 2 liters
- Overall Diameter: 12.17", 309.12 mm
- Baffle Hole Diameter: 11.13", 282.7 mm
- Front Sealing Gasket: Yes
- Rear Sealing Gasket: Yes
- Mounting Holes Diameter: 0.24", 6.1mm
- Mounting Holes B.C.D.: 11.75", 298.5mm
- Depth: 5.1", 130 mm
- Net Weight: 7.9 lbs, 3.58 kg
- Shipping Weight: 9.8 lbs, 4.45 kgs

MATERIALS OF CONSTRUCTION
- Coil Construction: Copper voice coil
- Coil Former: Polyimide former
- Magnet Composition: Ferrite magnet
- Core Details: Non-vented core
- Basket Materials: Pressed steel basket
- Cone Composition: Hemp cone
- Cone Edge Composition: Paper cone edge
- Dust Cap Composition: Zurette dust cap
Dimensions and Weight in Packaging
8 Ohms
Shipping Weight: 9 lbs
Shipping Dimensions: 13 x 13 x 7 in
Manufacturer Part Number (MPN): GUIT-FIDDLE

For support or warranty questions, please contact the manufacturer:
Phone: 502-845-5622

Be the first to rate and review this product.

8 Ohms

$104.99
