Eminence CV-7516 Guitar Speaker (75 Watts, 12")

Give new life to your rig! The Eminence CV-7516 pairs perfectly with any compatible British-style amp that will accentuate the midrange.

The epitome of British tone with a complete tonal balance. Grunt and punch in the lows, warm/tailored mids, and nice, clear, open/airy highs.

From dialing a sound in, to rocking it out, Eminence professional audio and musical instrument loudspeakers have been the leading choice in audio applications worldwide since 1966. Eminence is dedicated to providing the best quality, value and service to meet your needs. Nowhere is that mission more evident than in their wide product selection, industry leading seven-year warranty, and unrivaled customer support. Designed and assembled by hand in the USA, Eminence is the most trusted name in the industry. Find out why the world's premier brands and countless audio enthusiasts and musicians rely on Eminence.


- 12 inch Guitar Speaker
- 75 Watt power range
- 16 ohm impedance
- Vintage classic British tone for blues, country, rock, indie and jazz genres of music
- Highly compatible Instruments include Lead/Rhythm Guitar
- Overall Coloration is the epitome of British tone with a complete tonal balance grunt and punch in the lows, warm/tailored mids, and nice, clear, open/airy highs
WARNING: Cancer and Reproductive Harm - www.p65Warnings.ca.gov.

- Series: Patriot
- Model: CV-7516
- Application: 12" Open or Closed Back
- Configuration: 1, 2, or 4 X 12"
- Low End Response: Moderate
- Low End Shape: Tight
- Mid-Range Response: Aggressive
- Mid-Range Shape: Warm
- High-End Response: Moderate
- Volume/Power: Loudest
- Break-up Modes: Medum
- Nominal Basket Diameter: 12", 305 mm
- Nominal Impedance: 16 Ohm
- Watts: 75 W
- Resonance : 80 Hz
- Usable Frequency Range: 80 Hz - 5.7 kHz
- Sensitivity: 101.9 dB
- Magnet Weight: 56 oz.
- Gap Height: 0.313", 8 mm
- Voice Coil Diameter: 1.75", 44 mm
- Resonant Frequency (fs): 80 Hz
- DC Resistance (Re): 14.23 Ohm
- Coil Inductance (Le): 0.85m H
- Mechanical Q (Qms): 21.33
- Electromagnetic Q (Qes): 0.49
- Total Q (Qts): 0.48
- Compliance Equivalent Volume (Vas): 56.2 liters / 1.98 cu.ft.
- Peak Diaphragm Displacement Volume (Vd): 64 cc
- Mechanical Compliance of Suspension (Cms): 0.15 mm/N
- BL Product (BL): 20.05 T-M
- Diaphragm Mass Inc. Airload (MMs): 28 grams
- Efficiency Bandwidth Product (EBP): 163
- Maximum Linear Excursion (Xmax): 1.23 mm
- Surface Area of Cone (Sd): 519.5 cm2
Dimensions and Weight in Packaging
8 Ohms
Shipping Weight: 12.5 lbs
Shipping Dimensions: 14 x 14 x 7 in
Manufacturer Part Number (MPN): CV-7516
