Celestion EVH Guitar Speaker (20 Watts, 12")

No longer available at zZounds

Celestion EVH Guitar Speaker (20 Watts, 12"), Glamour View

zZounds Gear Experts Say...

Achieve that Van Halen tone through 4x12 cabinets with Celestion EVH Guitar Speakers. This speaker is a reproduction of the 1960s 20-watt Greenback speaker.

Overview

Edward Van Halen and Fender have joined forces to create the EVH guitar speaker. This incredible collaboration delivers ultimate Van Halen tone through 4 x 12 cabinets loaded with Celestion 'G12 EVH' speakers.

Throughout his career, EVH has sought out original Celestion 20-watt Greenback speakers to load into his recording and performing rigs. So, when designing the EVH 5150III cabinet it was to Celestion that EVH and Fender turned in search of that vintage Greenback sound.

Celestion's Heritage Series G12M speakers are a faithful reproduction of the original 1960s 20-watt Greenback and for EVH they provide the ideal solution. However - in order to give this speaker a look that is unmistakeably EVH - Celestion added a specially designed label, featuring the Van Halen logo and unique EVH striped design, along with a black-painted can that evokes the memory of the rare and much sought after Celestion 'Blackback' speakers.

NOTE: 15 ohms speaker is compatible with any 16 ohms cabinet.

Specs

Nominal diameter: 12 in., 305mm

Power Rating: 20 watts

Nominal impedance: 15 Ohms

Sensitivity: 96dB

Chassis type: Pressed steel

Voice coil diameter: 1.75 in., 44.5 mm

Voice coil material: Rounded copper

Magnet type: Ceramic

Magnet weight: 35 oz., 0.99 kg

Frequency range: 75-5000Hz

Resonance frequency, Fs: 75Hz

DC resistance, RE: 15 Ohms

Mounting Information
Diameter: 12.2 in., 309 mm

Overall depth: 5.1 in., 130 mm

Magnet structure diameter: 5.9 in., 150 mm

Cut-out diameter: 11.1 in., 283 mm

Mounting slot dimensions: 0.31 in., 7.9 mm diameter

Number of mounting slots: 4

Mounting slot PCD: 11.7 in., 297 mm

Unit weight: 7.9 lbs., 3.6 kg
